e Ast FULL LINE OVERVIEW L

AIR COMPRESSORS • VACUUM PUMPS

For applications requiring extremely quiet and highly efficient operation and simple maintenance, Gast's oilless Linear pumps have found widespread use in the medical, industrial, chemical, environmental, and scientific industries. Performance ranges from .39 to 8.9 cfm (11 to 252 lpm), pressures to 10.5 psig (0,72 bar), vacuum levels to 12.1 in. Hg (603 mbar), with an operating noise level as low as 28 dB(a). Operation is based upon the principles of electromagnetic oscillation - eliminating the need for sliding parts, minimizing power consumption, and offering high efficiency. Because there are no sliding parts there is no need for lubrication - the exhausted air is always clean and particle-free.

Performance

•Pressure to 10.5 psig (0,72 bar) •Vacuum to 12.1" Hg (603 mbar) •Air flow to 8.9 cfm (252 lpm)

Features •Oilless

• Long Life

• Low Noise Level •High Efficiency •Compact and Powerful •No Lubrication Necessary •Smooth Air Flow •Simple Maintenance

Typical Applications •Blood Cuff Monitors •Waste Water Treatment

• Environmental Monitoring and Air Sampling

•Oxygen Supply for Medical Instruments

•Liquid Agitation and Mixing

•Hospital Air Mattresses

•Medical Nebulizers

•Air Supply for Leak Test Equipment

•Solder Removal

•Automotive Emission Test Equipment

• Leak Test Equipment •Scientific and Medical Analysis

Equipment


	MAX. .	FREE AIR FLOW				MAXIMUM PRESSURE \|
MODEL/	POWER	cfm		lpm		psi		bar 1
SERIES	Watts	50 Hz	60 Hz	50 Hz	60 Hz	50 Hz	60 Hz	50 Hz	60 Hz
DDL8	14	.81	.81	23	23	3.2	3.2	0,22	0,22
DDL8B	14	.81	.81	23	23	3.2	3.2	0,22	0,22
DDL15	22	0.98	1.1	28	32	4.4	4.5	0,30	0,31
DDL15B	22	0.98	1.1	28	32	4.4	4.5	0,30	0,31
DDL30	36	2.3	1.9	65	54	5.1	5.4	0,35	0,37
DDL30B	36	2.3	1.9	65	54	5.1	5.4	0,35	0,37
DDL40	47	2.6	2.3	76	65	5.8	5.9	0,40	0,41
DDL40B	47	2.6	2.3	76	65	3.6	4.7	0,40	0,41
DDL60	63	3.6	2.8	102	79	6.1	6.3	0.42	0,43
DDL80	93	3.9	4.2	111	120	7.0	7.0	0,48	0,48
DDL120	138	6.0	5.9	169	167	6.1	7.0	0,42	0,48
DDL150	150	6.3	6.6	179	187	7.3	7.1	0,50	0,49

Electromagnetic oscillation of the rod/diaphragm assembly changes the volume of space enclosed between the casing and the diaphragm, creating pressure or vacuum.
