| | | | | | | | | | | | | | | | | | | | | | | | | | kastFULL LINE OVERVIEW | | | | | | | | | | | | For those vacuum applications where a regular industrial vacuum pump may not be preferred, Gast Vacuum Industrial generators provide an excellent alternative. Choose from 27 chemical and corrosion resistant models capable of achieving up to 27 in. Hg (99 mbar) with vacuum flow rates ranging from 0.2 to 158 cfm (0,3 to 268,5 m3/h). Single or multi stage designs offer several options, including High Vacuum, High Flow, combination High Performance, and Severe Duty Series. Also available are vacuum cups in flat and bellows, threaded or "slip fit" mounting options, with diameters from 1/4 to 57/8 in. | | | | | | Performance •Vacuum to 27" Hg (99 mbar) •Air flow to 158 cfm (268,5 m3/h) Features • Economical to Operate •Compact Size • Lightweight Construction • Low Air Consumption •No Moving Parts •Quiet Operation •Minimal Maintenance • Low Cost Typical Applications •Envelope Insertion/Extraction • Evacuation of Volatile Vapors •Aspiration •Carton Forming • Robotic Pick and Place •Any number of other vacuum applications where pump size, noise level or high-temperature environment are considerations. | | | | | | | | | | | | | | | | | | | | | | MODEL* | DESCRIPTION | FREE AIR FLOW | MAXIMUM VACUUM | AIR CONSUMPTION | | | | cfm @ 0" Hg | m3/h @ 1000 mbar | " Hg | mbar | cfm @ Suggested Operating Pressure | | | | VG-005-00-00 | | .2 | 0,3 | 27 | 99 | .46 @ 30-75 psi | | | | VG-010-00-00 | Single-Stage Hinh Vamiim | .95 | 1,6 | 26 | 133 | 1.60 @ 30-75 psi | | | | VG-015-00-00 | Higii vacuum Series | 2.2 | 3,7 | 27 | 99 | 3.50 @ 30-75 psi | | | | VG-020-00-00 | | 4 | 6,8 | 27 | 99 | 6.40 @ 30-75 psi | | | | VG-007-00-00 | | .46 | ,78 | 17 | 420 | .49 @ 70 psi | | | | VG-012-00-00 | Single-Stage Single-Stage | 1.6 | 2,7 | 17 | 420 | 1.90 @ 70 psi | | | | VG-022-00-00 | High Flow | 6.8 | 11,6 | 17 | 420 | 7.09 @ 70 psi | | | | VG-280-L0-00 | Series | 28 | 47,6 | 7.5 | 757 | 13.00 @ 80 psi | | | | VG-340-M0-00 | | 34 | 57,8 | 16.5 | 455 | 26.40 @ 80 psi | | | | VG-065-00-00 | Multi-Stage | 6.8 | 11,6 | 27 | 99 | 2.7 @ 68 psi | | | | VG-130-00-00 | High Vacuum | 12 | 20,4 | 27 | 99 | 4.9 @ 68 psi | | | | VG-260-00-00 | Series | 17 | 28,9 | 26 | 133 | 7.0 @ 68 psi | | | | VG-075-00-00 | Multi-Stage | 12 | 20,4 | 20 | 335 | 3.4 @ 87 psi | | | | VG-140-00-00 | High Flow Series | 16 | 27,2 | 20 | 335 | 5.5 @ 87 psi | | | | VG-131-00-00 | | 12 | 20,4 | 26 | 133 | 4.9 @ 68 psi | | | | VG-141-00-00 | Multi-Stage | 16 | 27,2 | 20 | 335 | 5.5 @ 87 psi | | | | VG-261-00-00 | Severe-Duty Series | 17 | 28,9 | 26 | 133 | 7.0 @ 68 psi | | | | VG-271-00-00 | | 26 | 44,2 | 20 | 335 | 13.4 @ 87 psi | | | | VG-260-02-00 | Multi-Stage | 36 | 61,1 | 26 | 133 | 14 @ 68 psi | | | | VG-260-04-00 | (Combination) High-Performance and Severe-Duty | 71 | 120,6 | 26 | 133 | 28 @ 68 psi | | | | VG-260-08-00 | 158 | 268,5 | 26 | 133 | 56 @ 68 psi | | | | | | | | | | | | | | | | | | | | | | | | | | When compressed air is forced through a conical nozzle, its velocity increases and pressure decreases. Gast vacuum generators operate on this venturi principle, which creates vacuum without a single moving part. | | | | | | •Metric models have MG prefix instead of VG. | | | | | | | | | | | | | | 20 | | | | | | | | | | | | | | | | | | | | | | | | | |
|
