Air Motors

up to 4 hp, speeds from 300 to 3,000 rpm, max. pressure 100 psi (7 bar)

MODEL

6AM-FRV-5A

(4 Vanes, Reversible)

6AM-FRV-23A

(8 Vanes, Reversible)Net wt. 21 lbs. (9,5 kg) inches / mm

FEATURES

1/2 NPT PIPE 7.47189,7 2.75 69,9

?Foot mounting?Any plane operation?Muffler AC990

4.38111,3 2.50 63,5 1.39 35,3 0.19 4,83 SQ. KEY

RECOMMENDED

5.81147,6

?Filter AH106F ?Regulator AH107R?Gauge AA806?Lubricator AH108L ?Oil AD220 – 1 quart (.94 litres) ?Repair kit K208 (4 Vane) ?Repair kit K281 (8 Vane)

3.50 88,9 0.625 15,88 DIA. 0.704 17,88 4.25108,0 1.74 44,2 5.00127,0 0.34 8,6 DIA.(4) HLS. 2.38 60,5

OPTIONAL

?Muffler AL476 (for additional noisereduction)

6AM-NRV-7A

(4 Vanes, Reversible)Net wt. 18 lbs. (8,1 kg)

FEATURES

?Face mounting?Any plane operation ?Muffler AC990 inches / mm

1/2 NPT PIPE 8.29210,6 2.75 69,9 1.94 49,3 2.44 62,0

RECOMMENDED

1.39 35,3 0.19

?Filter AH106F?Regulator AH107R?Gauge AA806 ?Lubricator AH108L ?Oil AD220 – 1 quart (.94 litres) ?Repair kit K208

4,83 SQ. KEY 2.31 58,7 2.50 63,5 DIA. 30 ° 0.625 15,88 DIA.

OPTIONAL

5.00127,0 2.00 50,8 R 0.70417,88

?Muffler AL476 (for additional noisereduction)

0.31 7,8711,1 -18 THD. 0.44 DP (3)

6AM-NRV-11A

(4 Vanes, Reversible)

6AM-NRV-22A

(8 Vanes, Reversible)Net wt. 24 lbs. (10,8 kg)

FEATURES

?NEMA 56C mounting?Any plane operation ?Muffler AC990 inches / mm

RECOMMENDED

8.29210,6 2.06 52,3 3.13 79,5

?Filter AH106F?Regulator AH107R?Gauge AA806 ?Lubricator AH108L ?Oil AD220 – 1 quart (.94 litres) ?Repair kit K208 (4 Vane) ?Repair kit K281 (8 Vane)

1/2 NPT PIPE 2.75 69,9 0.38 -16 THD. 9,65 (4 HLS.) 0.133,3 1.41 35,8 0.19 4,83 SQ. KEY 4.50 114,3 DIA.

OPTIONAL

5.88149,4

?Muffler AL476 (for additional noisereduction)

0.625 15,88 DIA. 45 ° 6.50165,1 0.70417,88
