Gauges ? Mufflers ? Foot Assemblies Gauges ? Mufflers ? Foot Assemblies

GAUGES

If a gauge is required for your Gast Regulator,please order as a separate item: Gast Part No.Used OnDescription AA807AH101R Regulator
1 /
8 " NPS, 0-160 psiAA806AH104R
1 /
4 " NPS, 0-160 psiAH107R AH110R A

MUFFLERS

A Gast PartUsed Dimensions - in (mm) NumberOnABC AL444 (Plastic)1AM/1UP/NL221.36 (35) 5.26 ( 134) 1/8" NPT AF350 (Metal)1AM/1UP/NL221.06 (27) 2.81 (71) 1/8" NPTAL445 (Plastic)2AM/4AM/NL32/NL421.36 (35) 5.26 (134) 1/4" NPT AC980 (Metal)2AM/4AM/NL32/NL421.72 (44) 2.31 (59) 1/4" NPTAL476 (Plastic)6AM/8AM4.00 (102) 8.00 (203 )1/2" NPT AC990 (Metal)6AM/8AM2.72 (69) 2.94 (75) 1/2" NPTAG601* (Metal)16AM3.12 C C CABBB (79) 21.22 (539) 1 1/4" NPT

Metal Style Metal Style

(AC980 / AC990)Plastic Style(AL Series) (AF350 / AG601) Plastic version offers enhanced sound reduction because of patented acoustic material technology. Metal version offers sound reduction with smaller envelope dimensions.* Not included with 16AM series, but is recommended.

FOOT ASSEMBLIES FOR 1AM AND 1UP AIR MOTORS AND GEARMOTORS

FAST AND SIMPLE INSTALLATION

GAST now offers two foot assemblies in kit form: AG585 for 1AM and 1UP Air Motors, kit includes foot,three mounting screws and instruction sheet. AG586 for 1AM and 1UP Gearmotors, kit includes footand three mounting screws.
O 1.8446,7 B.C. 2.81 71,4 1.75 44,5

Air Motor Foot Assembly Gearmotor Foot Assembly

0.75 19,1 1.00 25,4 1.50 38,1 1.7544,5 2.44 62,0

AG585 AG586

0.28 7,112,7 X 0.50 LONG SLOT (2) O 2.0050,8 B.C. 3.75 95,3 2.50 63,5 0.69 17,5 1.5038,1 1.00 25,4 1.38 35,1 3.00 76,2 3.00 76,2

32

0.28 7,1 SLOT (4)
