i^nzfiW Get the right air motor with all the right options.
Whatever your rotary air motor power requirements, chances are we have what you're looking for.
Performance Overview
AIR MOTORS
OPERATING DATA
MAXIMUM TORQUE
MODEL
MAX.
SPEED
OUTPUT POWER
TORQUE
MAX. AIR
CONSUMPTION
MAX. SPEED
Page No.
rpm
hp
kW
lb. in.
Nm
cfm
m3/h
rpm
lb. in.
Nm
1AM (A)
10,000
0.45
0,33
2.75
0,31
20.5
35,1
650
5.60
0,65
5
IUP (B)
6,000
0.45
0,33
5.25
0,58
27
47
500
6.00
0,68
5
2AM (A)
3,000
0.93
0,68
19.50
2,20
30
49,5
350
26.10
3,05
6-7
4AM (A)
3,000
1.70
1,30
36.00
4,1
78
132,5
300
56.00
6,3
8-9
6AM (A)
3,000
4.00
3,00
84.00
10,00
128
228
300
115.00
13,00
10-11
8AM (A)
2,500
5.25
3,90
132.00
14,40
175
293
300
185.00
21,00
12-13
16AM (A)
2,000
9.50
7,00
290.00
34,00
275
475
300
372.00
43,00
14
*NL22(B)
4,000
.18
0,13
2.80
0,32
18.5
31
1000
4.30
0,49
16
*NL32(B)
2,000
.42
0,31
13.50
1,5
30
51
300
21.00
2,5
17
*NL42(B)
2,000
.82
0,61
25.50
2,90
41
70
500
44.00
5,0
18
*NL52(B)
2,000
2.50
1.86
78.75
8,90
68
115
500
100.00
11,3
19
* Oilless models
GEARMOTORS
OPERATING DATA
MAXIMUM TORQUE
MODEL
GEAR RATIO
MAX.
SPEED
LINE PRES.
OUTPUT POWER
TORQUE
MAX. AIR
CONSUMPTION
MAX. SPEED
Page
No.
rpm
hp
kW
lb. in.
Nm
cfm
m3/h
rpm
lb. in.
Nm
1AM-NRV
15:1
350
A
0.34
0,26
62
7,1
21.0
36
30
72
8,1
20
1UP-NRV
15:1
400
C
0.32
0,23
49
5,5
21.0
36
30
71
8,0
20
4AM-RV
10:1
300
B
1.26
0,94
274
31,0
57.5
98
30
425
48,0
21
4AM-RV
15:1
200
B
1.25
0,90
400
45,2
60.0
102
20
640
72,0
21
4AM-70C
20:1
150
A
1.17
0,87
487
55,0
71.0
120
15
740
83,6
22
4AM-70C
40:1
75
A
0.95
0,71
800
90,4
71.0
120
7
1255
141,8
23
4AM-70C
60:1
50
A
0.82
0,61
1040
117,5
71.0
120
5
1640
185,3
24
6AM-22A
10:1
300
A
3.40
2,54
720
81,4
130.0
221
30
950
107,4
25
6AM-22A
20:1
150
A
2.65
1,98
1100
124,3
130.0
221
15
1550
175,6
26
6AM-22A
40:1
75
A
2.10
1,57
1725
194,9
135.0
230
8
2500
282,5
27
8AM-32A
20:1
125
A
3.70
2,76
1850
209,1
177.0
301
15
2550
288,2
28
16AM-13
20:1
100
A
6.50
4,85
4175
471,8
275.0
468
15
5175
584,8
29
A - 100 psig and 7,0 bar line pressure for imperial and metric data, respectively. B - 80 psig and 5,5 bar line pressure for imperial and metric data, respectively. C - 60 psig and 4,1 bar line pressure for imperial and metric data, respectively.
Pictorial and dimensional data is subject to change without notice.
The information presented in this catalog is based on technical data and test results of nominal units. It is believed to be accurate and is offered as an aid in the selection of Gast products. It is the user's responsibility to determine suitability of the product for intended use and the user as­sumes all risk and liability whatsoever in connection therewith.
