General Catalogues - Gandus Saldatrici - #2

Vertical form-fill-seal machine to create bags with three hermetic seals starting from a reel of thermoseleable film. Suitable to heavy duty packing of grains or powder products. Built in

painted steel, PLC for the setting and the control of the machine and all its functions.

Filling chute built in AISI 304 steel. Suitable to

be interfaced with filling and dosing automatic

systems.

Rotary sealing machine for packaging sterile products using paper/PPE or Tyvek® pouches to ISO 11607 standard. 15 mm wide multi-seal for maximum seal integrity, a sealing speed of 10 metres / minute for large volumes. Built-in dot matrix printer to print directly onto the pouch, details such as dates, codes, operators or any other information required to fully comply with required tracking. External thermal label printer can be attached to produce bar codes or other data on adhesive labels or a bar code scanner can be attached via the external COM port RS232.

High productivity rotary heat sealer for PP - AL/ PE -PA/PE heavy duty bags. Available in painted steel and stainless steel versions. Adjustable infeed speed 2-12 metres/minute. Temperature and sealing pressure digital control. It can be supplied as independent sealing unit or as part of automatic packaging lines.

Mounted on a stand with locking castors with adjustable in height sealing line. It can be linked to an independent band conveyor for bags up to 50 kg. It can be supplied also in ST version, only sealing head.

Coding device on demand.

This impulse sealer is specially designed for medical, dental, ophthalmic surgeries or laboratories, for sealing sterilisation pouches, to ISO 11607 standard.

Electromagnetic operated. Seal length 350 mm. Electronic time control with auto-test function to check the sealing element temperature. Supplied complete with roll dispenser and cutting device.

High productivity rotary heat sealer for PP - AL/ PE - PA/PE bags. Available in painted steel and stainless steel versions. Adjustable infeed speed 2­10 metres/minute. Temperature and sealing pressure digital control. Supplied with stand with locking castors and band

Compact constantly heated sealer for sterilisation pouches, ideal for use in dentist, doctors and veterinary surgeries or laboratories. It seals pouches up to 300 mm in width, operated by a simple lever with an electronic timer giving consistent results every time. An electronic control maintains accuracy of temperature. No consumables are needed. It can be used on a table on any suitable surface and is supplied complete with and integral reel holder. Extremely reliable and user friendly, highly regarded for its strong structure and attention to detail.

Fully validatable rotary sealers for sterilisation pouches with built In printer and full control of all sealing parameters. The machine fulfils all the requirements of an advanced sterilisation department and fully complies to ISO 11607 standards. Total control of the functions of the machine and complete traceability due to a storage capacity of 6000 sealing parameter records.

New alphanumeric LCD Keyboard, with 4 lines for quick access to all the machines functions, an integral printer,

conveyor adjustable in

height for bags max weight 10 kg, max height 600 mm. Coding device on demand.

Rotary sealing machine for closing sterilisation pouches to ISO 11607 standard. Functions include a 12 mm multi-line seal, stand by with auto start via optical sensor and ' adjustment of the sealing pressure to suit the thickness of the material. Constructed in epoxy powder coated stainless steel, equipped with a digital electronic temperature control with LCD display and supplied with a product support tray.

with a choice of 1 or 2 line printing. Two COM ports for interface with external systems such as exporting the parameter stored records and a Sealing speed of 10 metres/minute for high productivity. Touch version has a touch screen for programming and viewing of sealing parameters. Its highly advanced software allows it to be used in either CSSD or industrial environments, sharing the data required for validation of the sealing process to meet the ISO 11607 standard. Through a connection to a computer via Ethernet it is possible to program the machine remotely, share and save sealing parameter history for archiving and diagnose any incorrect functions within the process. Up to 3,000,000 sealing parameters and 24 packaging programs can be stored and the sealing speed is adjustable from 3 to 13 metres/minute.

High productivity rotary heat sealer for PP - AL/ PE - PA/PE bags of any thickness and dimension. Available in painted steel and stainless steel versions. Adjustable infeed speed 2-10 metres/minute. Temperature and sealing pressure digita control. Supplied with stand with locking castors and band conveyor adjustable in height for bags max weight 10 Kg height 600 mm. Coding device on demand.

An impulse sealing machine for closing medical pouches to ISO 11607 standard. Simple safe operation, with consistent high quality seals in a compact design. Double sealing bars are operated

electromagnetically, which can be activated manually or by foot pedal. Electronic control for sealing and cooling times. Available complete with roll dispenser and cutting device. The Digital Accutemp versions guarantee accurate control of the sealing parameters during each cycle which enables complete validation of the sealing process to ISO 11607 standard. It can be linked to a PC for recording, cycle by cycle, all the sealing parameters. A dedicated software installed on the PC, manages all the date for trceabilty of the sealing process.

High productivity rotary heat sealer for PP - AL/ PE - PA/PE heavy duty bags. Available in painted steel and stainless steel versions. Adjustable infeed speed 2-12 metres/minute. Temperature and sealing pressure digital control. It can be supplied as independent sealing unit or as part of automatic packaging lines. Mounted on a stand with locking castors with adjustable in height sealing line. It can be linked to an

independent band conveyor for bags up to 50 Kg. It can be supplied also in ST version, only sealing head. Coding device

demand

Gandus Saldatrici supplies a wide and complete range of dosing systems, designed to satisfy the most different requirements with ad hoc solutions. Vibrating conveyors, belt systems, auger dosing units, volumetric cup fillers, vibrating counters. They perfectly compliment Gandus Saldatrici automatic packaging machines and are also separately available.

Vertical form-fill-seal machine to create bags with three hermetic seals starting from a reel of thermoseleable film of max reel width 450 mm, 550 mm, 650 mm. Constant heated crimped seal, suitable for coated materials: polypropylene, aluminium/polyethylene, paper/polyethylene. Small dimensions, to be placed even in small production areas. Extremely competitive

price/quality relationship, with the warranty of a high reliability. Fully PLC settable, suitable to be interfaced with filling and dosing automatic systems. Developped in different

versions, to pack liquid, grains or powder products, and for food and non food market. Also available in C-90 version to create bags with vertical seal on the side area, built in AISI 304 steel, or with 40° inclined painted steel structure suitable for delicate and/or heavy products.

Filling and dosing electronic unit with 4 vibrating channels

This user friendly rotary sealer was developed for operators who need high productivity and reliability. Sealing at 10 metres/minute with a clear two line LCD display and polycarbonate user friendly keyboard allow easy reading or setting of the functioning data featuring a quick and simple menu for both temperature and counter.

New high productivity rotary heat sealer for any heatsealable material bags. Forerunner of a brand new generation of industrial rotary sealers, fully redesinged both structurally and functionally, Gandus RO 3003 stands out in the crowd for its extraordinary flexibility in use, and its capability of working with all types of heat sealable materials.

New RO 3003 guarantees a sealing width of 15 mm on bags in PE, Polyester/PE -AL/PE - PA/PE.

Designed to be the sealing station along automatic sacking lines, or used as independent heat sealer, max sealing speed up to 20 metres/minute, dua temperature digital controllers, cooling by forced air, seal pressure adjustment, available with printing by thermal transfer or inkjet. On stand with locking castors with adjustable in heigth sealing head, electrical components and control panel placed in a remote control box away from the sealing head, which prevents any contamination from the products.

This rotary sealer is designed for the sealing and coding of medical pouches in paper/polypropylene or Tyvek® materials to the ISO 11607 standard. It has a 12 mm wide multi-line seal, a user friendly operator keyboard and a sealing speed of 10 metres/minute. The print function is easy to use and set, using the built-in dot matrix printer to print dates, codes, operators, directly onto the pouches to comply with the most recent traceability standards.

Counting and alignment systems through circular vibrating cups or linear vibrating channels.

Vertical form-fill-seal machine to create bags with three hermetic seals starting from a reel of thermoseleable film of max reel width 450 mm, 550 mm, 650 mm. Thermocontrolled impulse flat seal with ROPEX digital main board. Developped for polyethylene and cast polypropylene film. Small dimensions, to be placed even in small production areas. Extremely competitive price/quality relationship, with the warranty of a high reliability. Fully PLC settable, suitable to be interfaced with filling and dosing automatic systems. Developped in more, different versions, for packing of metal and plastic small parts. Also available with 40° inclined painted steel structure suitable for delicate and/or heavy products.

Filling and dosing electronic unit with 2 vibrating channels suitable for pre­made bags of medium dimensions.
