Ethernet/RS232 Econo 1–8 axes

General Catalog - 14278 DMC-21x3 Series

DMC-21x2 - H- DC24 - DIN - VPAxis number 100-pin & Enet/RS232 Connectors DC-to-DC ConverterDIN-rail Mount Molex Power Connector x=1 thru 8 H=horizontal (default) - none (default) - none (default) VP=vertical (default)V=vertical - DC24 (18–36 Volts) - DIN (requires –V option) HP=horizontal-DC48 (36–72 Volts)

The default configuration of the DMC-21x2 is with horizontal connector mount for the communication and 100-pin connectors and vertical mount for the power connector,no DC-to-DC and no DIN rail mount.

DMC-21x3 - V - DC24 - DIN - UP - VPAxis number Enet/RS232 Connectors DC-to-DC Converter DIN-rail Mount 96-pin config.Molex Power Connector x=1 thru 8 V=vertical (default)- none (default) - none (default) - UP (default) VP=vertical (default)H=horizontal -DC24(18–36 Volts) - DIN (requires –V - DOWN HP=horizontal-DC48 (36–72 Volts) and UP option) - RA (right angle)

The default configuration of the DMC-21x3 is with vertical communication and power connector mount,no DC-to-DC,no DIN rail mount and UP 96-pin connector configuration.ICM and AMP modules only mate with DMC-21x3-V-UP-HP.Only -DC and -DIN need to be specified when ordering DMC-21x3 with AMP or ICM. CONTROLLERS—ETHERNET

Ordering Information

PART NUMBERDESCRIPTIONQUANTITY 1 QUANTITY 100 DMC-2112 1-axis Ethernet10BASE-T,RS232 card,100-pin SCSI$795$ 595 DMC-2122 2-axis Ethernet 10BASE-T,RS232 card,100-pin SCSI$895$ 665 DMC-2132 3-axis Ethernet 10BASE-T,RS232 card,100-pin SCSI$1045$ 725 DMC-2142 4-axis Ethernet 10BASE-T,RS232 card,100-pin SCSI$1195$ 795 DMC-2152 5-axis Ethernet 10BASE-T,RS232 card,100-pin SCSI$1295$ 845 DMC-2162 6-axis Ethernet 10BASE-T,RS232 card,100-pin SCSI$1395$ 895 DMC-2172 7-axis Ethernet10BASE-T,RS232 card,100-pin SCSI$1495$ 945 DMC-2182 8-axis Ethernet 10BASE-T,RS232 card,100-pin SCSI$1595$ 995 DMC-2113 1-axis Ethernet10BASE-T,RS232 card,96-pin DIN$795$ 595 DMC-2123 2-axis Ethernet 10BASE-T,RS232 card,96-pin DIN$895$ 665 DMC-2133 3-axis Ethernet 10BASE-T,RS232 card,96-pin DIN$1045$ 725 DMC-2143 4-axis Ethernet 10BASE-T,RS232 card,96-pin DIN$1195$ 795 DMC-2153 5-axis Ethernet 10BASE-T,RS232 card,96-pin DIN$1295$ 845 DMC-2163 6-axis Ethernet 10BASE-T,RS232 card,96-pin DIN$1395$ 895 DMC-2173 7-axis Ethernet10BASE-T,RS232 card,96-pin DIN$1495$ 945 DMC-2183 8-axis Ethernet 10BASE-T,RS232 card,96-pin DIN$1595$ 995 DMC-31x3 DMC-21x3 with distributed control functionalitySame price as DMC-21x3 -DIN DIN-rail mountoption for DMC-21x2/x3$100$ 50 -BOX Metal enclosure for DMC-2143 and ICM-20105 $100$ 75 -DC12 DC-to-DC converter for 9 V to18 V$100$ 70 -DC24 DC-to-DC converter for 18 V to 36 V$100$ 70 -DC48 DC-to-DC converter for 36 V to 72V$100$ 70 DB-28040 I/O expansionboardfor 8 analog inputs and 40 digital I/O (outputs sink/source 3.3 V)$295$ 195 DB-28040-5V I/O expansionboard for 40 digital I/O and 8 analog inputs.Outputs sink/source 5 V.$295$ 195 DB-28104 Sinusodial Encoder Interpolation Board$395$ 245 ICM-20100 DMC-21x3 Interconnect with D-type connectors (use1for every4 axes)$95$ 75 ICM-20105 DMC-21x3 Interconnect for optically isolated I/O (use 1 for every 4 axes)$195$ 145
Accessories for DMC-21x2/x3 arecontinued on the nextpage. www.galilmc.com / Galil Motion Control,Inc. 49
