GAI-Tronics Telephony PHP400 Hands-Free, Vandal Resistant, Disability-Friendly Telephone TECHNICAL SPECIFICATIONS Casing Material mild steel, zinc coated, powder coat finish white. Call for other options. Disability Features Raised text and Braille legend to button; Integral induction loop Keypad Raised, stainless steel, vandal resistant pushbutton (palm operable) Temperatures Operating temperature: -20 to +60° C Storing: -40° C to +70° C Lightning / Transients Protection to ITU-T k.21 enhanced levels Weather Resistance IP65 Humidity 95% RH non condensing Weight: ~6kg External I/O 4 auxilliary inputs, 2 isolated relay outputs (1 capable of switching 230Vac) Monitoring and reporting Remote alarms via syslog or email DIMENSIONS 405mm diameter x 88mm depth (button protrudes a further 10mm from front panel) Mounting centres: 145 x 270mm ANALOGUE / GSM Speech Voice-switched (VOX) semi-duplex operation Call timeout programmable from 1 to 42 minutes. Remote switch-off capability Dialling Autodial keypad single-press switch-on-and-dial 24 digits maximum with embedded Recall, Pause, Pulse & Tone characters Ringing Dual tone ringing through loudspeaker >75 dB @ 1m REN 1 Power Supply 230Vac @ 650mA max 2 Memory Retention (autodiallers) E Prom - 10 year life Options: Remote programming Auto-dial numbers, time-out and dial mode can be programmed over the phone line either from a tone phone or from monitoring software (TMA). Configuration Remotely programmable via TMA Remote monitoring Remote health-check and fault reporting, either on a call-in or polled basis. TMA required. Call Logging Records call time, duration and auto-dial number used. TMA required. VOICE OVER IP - SIP Connection type SIP to RFC3261 Ethernet connection via RJ45 socket inside enclosure Power supply Power requirement: 230Vac @ 650mA max (typ 50mA in idle state), or optional 48Vdc @ 1A max Mains connection via screw terminals inside enclosure Cable access: single 20mm hole to both top and bottom of enclosure (blanking plugs supplied). Call set-up Protocol Session Initiation Protocol (SIP) (RFC 3261) only Configuration Remote configuration via web pages, serial port, Telnet or configuration file Static IP address provisioning or DHCP APPROVALS This mark indicates compliance with the: Radio & Telecommunications Terminal Equipment Directive 1999/5/EC (R&TTE) 2002/96/EC - Waste Electrical and Electronic Equipment (WEEE) Directive 2002/95/EC - Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) Tested to CTR21 Network Rail Approved For specific country approval, please call ORDER INFORMATION For order codes and details, please contact T: 01283 500500, F: 01283 500400, E: sales@gai-tronics.co.uk OPTIONAL ACCESSORIES Please ask for Brochure B150 or visit www.gai-tronics.co.uk GAI-Tronics® - United Kingdom - Tel: +44 (0)1283 500500 - Fax: +44 (0)1283 500400 - www.gai-tronics.co.uk GAI-Tronics® (Corporate) - USA - Tel: +1(610) 777 1374 - Toll Free: 800 492 1212 - Fax: +1(610) 796 5954 - www.gai-tronics.com GAI-Tronics® S.r.l - Italy - Tel: +39 02 48601 460 - Fax: +39 02 4585 625 - www.gai-tronics.co.uk GAI-Tronics® - Malaysia - Tel: +60 3 8945 4035 - Fax: +60 3 8945 4675 - www.gai-tronics.co.uk GAI-Tronics® Austdac - Australia - Tel: 011 61 28 851 5000 - Fax: 011 61 29 899 2490 - www.austdac.com.au An ISO 9001, ISO 14001, OHSAS 18001 Registered Company The policy of GAI-Tronics is one of continuous improvement; therefore the company reserves the right to change specifications without notice. B189-2-0512B/CN36751-001
