(Metal Foil Strain gage Technology)

Load cells New ModelOld ModelDescriptionDimensions

(in.)

Specifications LSB350 L2350/2351

S Beam Tension/Compression

Rated Output (RO)

..... 2 mV/V nom. Anodized Aluminum (500 to 1K lbs)

Nonlinearity

................ ±0.05% RO

500, 1K, 2K

17-4 stainless steel (2K lb)

A = 2.0B = 1.0 C = 3.0 *D = 1/2-20 * Metric thread available: Hysteresis

................... ±0.05% RO

lb

4 Pin Lemo Receptacle, Standard

DBC Operating Temp

......... .-60 to 200°F 28 Awg, 6 conductor shielded Polyurethane cable, 5 ft optional Weight 7.5 oz (aluminum), 18 oz (stainless steel) Also available in metric

D = M12x1.75A Excitation (max)

......... 20 VDC

Industrial bridge Resistance

....

1000 Ω nom.

Deflection

................... 0.003 to 0.01” nom. Wiring Code .................. WC4, CC4

LSB352 L2372

3 mV/V S Beam w/ Overload Protection

Rated Output (RO) ..

3 mV/V nom.


ABCD

Nonlinearity ............

±0.05% RO

500, 1K lb

Tension/Compression

A = 2.00B = 1.00C = 3.00D = 1/2-20

Hysteresis ...............

±0.05% RO

Overload Protection

17-4 stainless steel

Operating Temp ......

-40 to 200°F
 28 AWG, 6 conductor shielded Polyurethane
cable, 5 ft

Excitation (max) .....

18 VDC

Bridge Resistance ...

350 Ω nom. 350 Ω bridge 0.01 nom. Matched output option available

Deflection ...............

Weight:18 oz

Wiring Code ............

WC4

LSB353 L2362/2363

S Beam 3 mV/VTension/Compression

Rated Output (RO) ..

3 mV/V nom.

Nonlinearity ............

±0.05% RO

500, 1K2K, 3K

17-4 stainless steel

ABCD

A = 2.00B = 1.00C = 3.00D = 1/2-20

Hysteresis ...............

±0.05% RO

lb

28 AWG, 6 conductor shielded Polyurethane
cable, 5 ft

Operating Temp ......

-40 to 200°F 18 VDC 350 Ω bridge

Excitation (max) .....

Matched output option available

Bridge Resistance ...

350 Ω nom. Weight:18 oz

Deflection ...............

0.01 nom.

Wiring Code ............

WC4

LSB400 L2350/2351

S Beam Tension/Compression

Rated Output (RO)

..... 2 mV/V nom. 17-4 stainless steel

Nonlinearity

................ ±0.05% RO

5K, 10K

4 Pin Lemo Receptacle, Standard

A = 2.5B = 1.5C = 3.5 *D = 3/4-16 Hysteresis

................... ±0.05% RO

lb

28 Awg, 6 conductor shielded Polyurethane cable, 5 ft optional Weight 53 oz

DBC Operating Temp

.......... -60 to 200°F Also available in metric

Excitation (max)

......... 20 VDC
* Metric thread available:

Bridge Resistance

.....

350 Ω nom.

D = M16x2A Deflection

................... 0.003 to 0.01” nom. Wiring Code .................. WC4, CC4

LSB453 L2364

3 mV/V S BeamTension/Compression

Rated Output (RO) ..

3 mV/V nom.

Nonlinearity ............

±0.05% RO

5K lb

17-4 stainless steel

ABCD

Hysteresis ...............

±0.05% RO 28 AWG, 6 conductor shielded Polyurethane cable, 5 ft 350 Ω bridge

A = 3.00B = 1.30C = 4.25D = 3/4-16

Operating Temp ......

-40 to 200°F Matched output option available 18 VDC Weight: 44 oz

Excitation (max) ..... Bridge Resistance ...

350 Ω nom.

Deflection ...............

0.015 nom.

Wiring Code ............

WC4

LSB503 L2365

3 mV/V S BeamTension/Compression

Rated Output (RO) ..

3 mV/V nom.

Nonlinearity ............

±0.05% RO

10K lb

17-4 stainless steel

ABCD

Hysteresis ...............

±0.05% RO 28 AWG, 6 conductor shielded Polyurethane cable, 5 ft 350 Ω bridge

A = 3.50B = 1.30C = 4.75D = 3/4-16

Operating Temp ......

-40 to 200°F Matched output option available 18 VDC Weight: 60 oz

Excitation (max) ..... Bridge Resistance ...

350 Ω nom.

Deflection ...............

0.015 nom.

Wiring Code ............

WC4

LSB600 L2355/2356

Cylindrical S Beam High Capacity/Canister Tension/Compression

Rated Output (RO) ..

2 mV/V nom.

A = 2.74B = 4.75 Nonlinearity ............

±0.1% RO

10K, 25K lb

ACB

Hysteresis ...............

±0.1% RO 17-4 stainless steel

Operating Temp .......

-60 to 200°F Bendix
 receptacle: PT02A-10-6P
Standard Thread

Excitation (max) .....

18 VDC Weight: 7 lb

C = 1 1/4-12 Bridge Resistance ....

350 Ω nom.
Metric Thread Available

Deflection ................

0.005” nom.

C = M36x3 Wiring Code .............

CC1

LAU200 L1050

Pedal Force/Accelerator Sensor

Rated Output (RO) ..

2 mV/V nom. 17-4 stainless steel one-piece construction

Nonlinearity ............

±0.2% of RO

10, 25, 50, 100300

Low profile, off-center loading error <4%

Hysteresis ...............

±0.2% of RO

lb

FSH00173 Lemo Weight: 6 oz
 mating with 10 ft PVC cable assembly included Detachable mounting plate with hose clamp mounting provision included

A = 2.00B = 0.38

Operating Temp ......

-60 to 200°F

Automotive

BA Excitation (max) .....

20 VDC

Bridge Resistance ...

700 Ω nom.

Mounting plate included

Deflection ...............

0.005 - 0.009” nom.

Wiring Code ............

CC4, WC1

LAU210 L1051

Pedal Force/Brake Sensor

Rated Output (RO) ..

2 or 3 mV/V nom. 17-4 stainless steel one-piece construction

Nonlinearity ............

±0.2% of RO

300, 454

Low profile, off-center loading error <4%
®

Hysteresis ...............

±0.2% of RO

lb

24 AWG, 4 conductor shielded Teflon cable, 10 ft

AB

Weight: 11 oz

A = 2.50B = 0.65

Operating Temp ......

-60 to 200°F

Automotive

Detachable mounting plate with hose clamp mounting provision included

Excitation (max) .....

20 VDC

Bridge Resistance ...

700 Ω nom.

Mounting plate included

Deflection ...............

0.002 or 0.003” nom

Wiring Code ............

WC1

LAU220 L1055

Spike Resistant Pedal Force sensor

Rated Output (RO) ..

2-3 mV/V nom.

Nonlinearity ............

±0.25% of RO

300, 500 lb

17-4 stainless steel one-piece construction

Hysteresis ...............

±0.25% of RO

AutomotiveINDUSTRYSTANDARD

Low profile, off-center loading error <1%

A = 2.58B = 0.65

Operating Temp ......

-60 to 200°F 24 AWG, 4 conductor shielded Teflon
® cable, 10 ft 20 VDC Weight: 16 oz

Excitation (max) .....

BA

Detachable mounting plate with hose clamp mounting provision included

Bridge Resistance ...

700 Ω nom.

Mounting plate included

Deflection ...............

0.006” nom.

Wiring Code ............

WC1

LAU300 NEW PRODUCT

Industrial seat Belt Sensor

Rated Output (RO) ..

2 mV/V nom. Tests tension forces on seat belts

Nonlinearity ............

±0.25% of RO

3K lb

Accepts belts up to 0.1 Thk

A

±0.25% of RO Anodized Aluminum

Hysteresis ...............

Automotive

24 Awg, 4 conductor shielded Teflon cable, 10 ft Long Weight 0.3 lb

A= 2.91B= 0.93

Operating Temp ......

0 to 200°F

B

Excitation (max) .....

18 VDC

Bridge Resistance ...

350 Ω nom.

Wiring Code .............

WC1

8

LSB =S-Beam LAU =Automotive

Extraneous Load Factors Available (Please visit www.futek.com or contact factory for details)
