PoweredAxle
227
_0142__
The PoweredAxle can be tailored to individual customer requirements
Customers can either select our standard range or specify :-
•Shaft details
•Brake Type
•Motor Length
•Supply lead configuration
MOTOR SPEED 0 I 2500 I 3000 I 3500 I 4000
PoweredAxle Selection Table
1500
RATIO
GEARBOX OUTPUT TORQUE [Nm]
GEARBOX OUTPUT SPEED [RPM]
A
B
C
D
E
1
2
3
4
5
6
R8
8:1
11.1
8.6
5.8
4.7
2.9
175
233
292
350
408
467
R10
10:1
13.6
10.5
7.1
5.7
3.5
143
190
238
285
333
381
R1 1
11:1
14.6
11.3
7.6
6.2
3.8
133
177
222
266
310
355
R12
12:1
15.7
12.1
8.2
6.6
4.1
124
165
206
248
289
330
R13
13:1
16.9
13.0
8.8
7.1
4.4
115
153
192
230
268
307
R15
15:1
19.7
15.2
1 0 .3
8.3
5.1
99
132
164
197
230
263
R16
16:1
21 .3
1 6.5
11.1
9.0
5.5
91
121
152
182
213
243
R18
18:1
23.2
17.9
1 2 .1
9.8
6.0
84
112
140
168
196
223
R21
21:1
27.7
1 4.4
1 1 .6
7.2
70
94
117
140
164
187
PM62425
60
80
100
115
135
150
PM62432
100
130
160
190
220
240
PM62440
120
160
200
235
275
300
PM62465
180
240
300
350
400
430
PM62490
250
320
400
450
500
500
The rating table assumes 24 V DC supply, for other voltage ranges please contact our sales team.
Basic design
MOTOR SIZE
OUTPUT POWER [WATTS]
