| H Low-level limiter of "high-integrity design": level electrode NRG 16-40, level switch NRS 1-40.1 ...................p. 20 HI Modulating level controller: level probe NRG 26-40 ........................................p. 22 El High-level alarm of "high-integrity design": level electrode NRG 16-41*).....................................p. 21 Eld] Conductivity measurement and continuous/intermittent blowdown: conductivity electrode LRG 16-40, continuous blowdown controller LRR 1-40, continuous blowdown valve BAE, intermittent blowdown valve MPA, 3/2-way pilot valve, strainer............................p. 26 E Sample cooler...............................................p. 29 El Blowdown flash vessel ED Residual blowdown cooler El Blowdown receiver H Safety temperature limiter at the superheater: resistance thermometer TRG 5-65. temperature preamplifier TRV 5-40 ...............................p. 24 M Safety valve GSV El Pressure limiter DSF El Pressure controller/transmitter E Disco non-return valve RK 86 El Strainer GSF E Stop valve GAV E Electrical/pneumatic control valve V 725 M Process data acquisition SPECTORconfro/ with interfaces: CAN, MODbus, Ethernet, modem, Profibus (optional M Monitoring of the fresh water: t Demineralization equipment - using conductivity monitoring t Partial demineralization equipment: by monitoring residual hardness (not part of our product range) | ||||||||||||
| The benefits in detail | ||||||||||||
| Better overview of the process Better overview of the process through centralized process display Actual values indicated as bar chart Trend plot of the measurement values Prioritized display of faults List of maintenance intervals Totalizing of consumption Increased safety Designations of the measurement quantities, input/output signals, and logging/alarms can be configured by the plant operator All signals, limits and warning levels can be logically linked (NAND, NOR, RS-FF etc.); the result is available as a switching output/ logging signal Environmental protection through active monitoring of waste water and exhaust gases Reduced cost Better utilization of fuel Integrated control circuits, i.e. separate electronic control units are no longer needed. Easily integrated and expanded Modular structure, therefore extendable and suitable for all plant sizes Existing input and output signals are easy to integrate | ||||||||||||
| *) If the high-level alarm does not act on the safety chain, the level switch NRS 1-41 is required. | ||||||||||||
| 9 | ||||||||||||
