Alligator® Rivet Fasteners

FASTENERS

(300 SERIES STAINLESS PLATES)

Sold only In case quantities. 10 Packs/case, 10 pack minimum


BELT		ORDERING	ITEM	UNIT OF
WIDTH		NUMBER	CODE	MEASURE
		WITH STEEL CORRUGATED HEAT-TREATED
in.	mm		HINGE PINS
4	100	ARJ4/100	15000	Package
6	150	ARJ6/150	14983	Package
7	175	ARJ7/175	15001	Package
10	250	ARJ10/250	15002	Package
14	350	ARJ14/350	15003	Package
WITH 300 SERIES STAINLESS SPRING WIRE HINGE PINS
6	150	ARJ6/150SSI i 14995 \| Package

NOTE: Each package includes fasteners, rivets and hinge pins for 2 complete splices.

HAND APPLICATOR TOOL

MULTIPLE RIVET INSTALLATION TOOL

Includes tool with guide block, pneumatic punch and hand punch


DESCRIPTION	ORDERING NUMBER	ITEM CODE	WT. LBS.
7" (175 mm) Installation Kit	MART-7	15025	9.1
14" (350 mm) Installation Kit	MART-14	15026	12.4
REPLACEMENT PARTS
Pnuematic Punch	AR1P	15027	.2


DESCRIPTION	ORDERING NUMBER	ITEM CODE	WT. LBS.
7" (175 mm) Installation Tool 14" (350 mm) Installation Tool	ART-7 ART-14	15004 15005	6.9 10.1

COMPLETE TOOL KITS - HAND

APPLICATOR TOOL

Each kit includes an Installation Tool, Belt Hand Skiver, 1 lb. Hammer, Pin Bender and 2 packages of Alligator Rivet Fasteners. Packaged in a durable plastic tool box.

NOTE: When using the pnuematic punch, air pressure not to exceed 85 psi.

COMPLETE TOOL KITS - MULTIPLE RIVET INSTALLATION TOOL

Each kit includes a multiple rivet installation tool, guide block with screws, two pnuematic punches, hand punch and air hammer. Packaged in a durable plastic tool box.


DESCRIPTION	ORDERING	ITEM	WT.
DESCRIPTION	NUMBER	CODE	LBS.
7" (175 mm) Installation Kit	ARTK-7	15006	14.5
14" (350 mm) Installation Kit	ARTK-14	15015	18.5


DESCRIPTION	ORDERING NUMBER	ITEM CODE	WT. LBS.
7" (175 mm) Installation Kit 14" (350 mm) Installation Kit	MARTK-7 MARTK-14	15032 15033	16.5 19.7

REPLACEMENT HINGE PINS


BELT WIDTH		ORDERING NUMBER	ITEM CODE	QTY PKG.	NUMBER	ITEM CODE	QTY. PKG.
in.	mm	arsh STEEL CORRUGATED HEAT-TREATED HINGE PIN			arss1 300 SERIES STAINLESS SPRING WIRE PIN
4"	100	ARSH4/100	14990	9	ARSS1-4/100	15007	9
6"	150	ARSH6/150	14991	8	ARSS1-6/150	15017	8
7"	175	ARSH7/175	14992	8	ARSS1-7/175	15008	8
10"	250	ARSH10/250	14993	4	ARSS1-10/250	15009	4
14"	350	ARSH14/350	14994	4	ARSS1-14/350	15010	4

NOTE: When using the pnuematic punch, air pressure notto exceed 85 psi.

ARSS1

ARSH

REPLACEMENT PARTS


DESCRIPTION	ORDERING NUMBER	ITEM CODE	WT. LBS.
Punch	AR1P	15027	.20
Guide Block 7"	MARGB-7	15028	1.0
Guide Block 14"	MARGB-14	15029	1.6
Cam LeverAssembly	ART7-7	15012	.1
Cam Lever Spring	ST5-3	50015	.1
Clamp Bar 7"	ART7-5	15013	.8
Clamp Bar 14"	ART14-15	15014	1.3
Guide Block Post	MART-GBPW/S	15031	.1
Guide Block Knob	MART-GBK	15030	.3
FeltWashers (2 per Package)	MART-GBFW	15035	.1

EXTRA RIVETS (type 430)


DESCRIPTION	ORDERING NUMBER	ITEM CODE
15/PKG.	AR3-15	15011

ALLIGATOR® BELT GRINDER


ORDERING NUMBER	ITEM CODE	WT. LBS.
RB-1	30867	.7

7J Stock Items (non-shaded) carried in factory inventory.

I I Made To Order Items (shaded) allow one week for production.

In most cases, the next standard stock item can be adapted to meetyour requirements.

Non-Listed Items are available. Request quote for price and delivery.
