9 FISCHERSCOPE® X-RAY XUL® and XULM® The models of the XUL series are compact X-ray fluorescence spectrometers for coating thickness measurements and material analyses. X-ray source and detector are located underneath the measurement chamber. This allows for simple and precise positioning of the specimens to be measured. The XUL instruments are suited for measurements of small parts with different shapes, such as screws, bolts or nuts, for contacts and other electronic components. The metal content of electroplating baths can be analyzed quickly and easily as well. The XULM with micro focus tube is designed for measurements on very small parts, plug contacts and wires. It also includes four motor-adjustable apertures and three different primary filters for optimum signal to noise ratio. It is, therefore, particularly well suited for the jewelry and watch industries but also for manual measurements on PCBs. FISCHERSCOPE® X-RAY XDL® The instruments of the XDL series are used in quality assurance, incoming inspections and in production monitoring. They are particularly well suited for measurements on large specimens with complex shapes due to the easily accessible measurement chamber. Typical applications are measurements of electroplating coatings on mass-produced parts, but also functional coatings in the electronics and semiconductor industries. XDL instruments can measure corrosion protection coatings and decorative multi-coatings such as chrome on nickel on copper quickly and precisely. Due to its modular design, the XDL series can be equipped with various XY stages and a Z-axis. In the design with a programmable XY stage, the XDL can be used for automated testing jobs. COATING THICKNESS MATERIAL ANALYSIS
