5 DELTASCOPE® FMP10 and FMP30 ISOSCOPE® FMP10 and FMP30 DUALSCOPE® FMP20 and FMP40 The FMP hand-held instruments measure coating thicknesses with high precision and non-destructively. Magnetic induction method (DELTA), with eddy current (ISO) or both methods (DUAL). They are modern, robust and user friendly and can be adapted to any measuring application using interchangeable probes. FMP10 and FMP20 are entry-level models for professional metrology, ideal for repetitive measuring applications. FMP30 and FMP40 additionally feature various strategies for structured data collection, more memory and Bluetooth®-data transfer. Extensive graphical and statistical evaluation capabilities make them well suited for complex measuring applications. DUALSCOPE® FMP100 Most advanced in the FMP family, this device offers an extremely user-friendly operation via high-resolution color touch screen and the WindowsTM CE operating system. The DUALSCOPE® FMP100 is a universal solution, using magnetic induction and the eddy current methods. The DUALSCOPE® FMP100 is ideal for different measurement applications. Specific settings and calibrations can be stored and recalled easily. In addition to extensive evaluation and statistics functions, the FMP100 offers flexible graphical presentations of the measurement data. An innovative tool for quality control, the FDD®-Software (Factory Diagnosis Diagram) is integrated. COATING THICKNESS
