PowerMax Pulleys & Idlers - 16 Pages

7 V-Belt Idlers PowerMax V-Belt Idlers are designed for strength and durability. For use with standard A, B and 5V section belts in a variety of industrial applications. The use of radial supporting ribs provides additional belt support and prevents groove deformation. Ideal for use with Fenner Drives RotaryTensioners. Mounting adapters are available to facilitate easy installation (see page 11). NOTES: Pulley diameters can be machined down below the pitch line of belt for material handling applications. t Insertion molded bearing. Part Number Type Grooves L A DIMENSIONS B C D E Belt Size Bearing Type Bore Size VA3001 1 1 3.00 2.00 .50 .70 .76 A 6203-2RS 17mm VA3002 1 1 3.10 1.84 .63 .78 .78 B 6203-2RS 17mm VA4001 1 1 3.98 2.99 .50 .70 .78 A 6203-2RS 17mm VA4002 1 1 4.00 2.84 .64 .86 .76 B 6203-2RS 17mm VA5001 1 1 5.04 3.84 .65 .80 .78 B 6203-2RS 17mm VA6001 1 1 6.03 5.12 .50 .72 .76 A 6203-2RS 17mm VA6250t 1 1 6.25 5.00 .61 .95 .67 A/B 6203-2RS 17mm VA7501 1 1 7.50 6.60 .54 .72 .71 A 6203-2RS 17mm V2B6280 2 2 6.28 5.18 .64 1.72 1.72 B/5V 6203-2RS .510/.520 V3B6280 2 3 6.28 5.18 .64 2.44 2.44 B/5V 6203-2RS .510/.520 V4B6280 2 4 6.28 5.18 .64 3.16 3.16 B/5V 6203-2RS .510/.520 Single Flange Idlers PowerMax Single Flange Idlers are designed specifically for use on conveyor corners but can be used for a variety of applications. Designed for use with B-section V-belts. Mounting adapters are available to facilitate easy installation (see page 11). NOTE: All dimensions are for reference only. www.fennerdrives.com

PowerMax Pulleys & Idlers
  1. P. 1

  2. P. 2

    2 PowerMax PULLEYS & IDLERS The PowerMax Advantage........4 Technical Data Material....................6 Bearings & Bearing Life.......6 V-Belt...
  3. P. 3

    Composite Idlers & Sprockets Fenner Drives is the industry leader in composite products for industrial power transmission and material handling applications....
  4. P. 4

    4 PowerMmx PULLEYS & IDLERS The PowerMax Advantage...  Molded of high-strength glass-reinforced nylon Օ Increased cable or belt life...
  5. P. 5

     Lighter-weight composite design means less energy for start up and running Օ AU catalog items are in stock for immediate shipment  Available...
  6. P. 6

    About Our Material Fenner Drives uses engineering composites, which ensure the highest level of performance and consistent strength. Our standard material...
  7. P. 7

  8. P. 8

    T-Max Belt and Chain Tensioners Catalog table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:3.50pt "Arial", sans-serif; } .font1...
  9. P. 9

    9 Round Belt Idlers PowerMax Round Belt Idlers are designed for use with round belts, ropes or cables. The deep uninterrupted groove provides continuous...
  10. P. 10

    10 Sprockets  Wear rթsistant glass-reinforced nylon  Insertion moldedABEC-1 high prթcision bearings  Lightweight and quiet Օ Corrosion...
  11. P. 11

    Mounting Adapters Versatile mounting adapters simplify the job of assembly and help to reduce overall cost. Made of high quality sintered iron materials,...
  12. P. 12

    12 DriveN Pulleys The latest innovation in composite power transmission components from Fenner Drives.  For use with A/4L section V-belts Օ Directly...
