12 DriveN Pulleys The latest innovation in composite power transmission components from Fenner Drives. For use with A/4L section V-belts Օ Directly interchangeable with industry standard "AK" type pulleys Molded premium quality glass-reinforced nylon material Օ Sintered mtal drive hub insertion molded for high strength Corrosion r镩sistant and lightweight State-of-the-art prթcision molding assures part consistency Highly cost effective Օ Bore sizes: 5/8", 3/4", 7/8", 1" Sa J. DD OD DD OD -L--I Type 1 Part Number L Type LU DIMENSIONS F H L Belt Size DIAMETER Outside Datum Number Spokes Spoke Style AFD44 1 .79 .74 2.17 1.53 A/4L 4.25 4.00 - - j AFD49 1 .79 .74 2.17 1.53 A/4L 4.75 4.50 4 I-Beam AFD59 1 .79 .74 2.17 1.53 A/4L 5.75 5.50 4 I-Beam AFD74 1 .79 .74 2.17 1.53 A/4L 7.25 7.00 4 I-Beam AFD84 2 .78 .75 2.22 1.60 A/4L 8.25 8.00 6 Cross AFD94 2 .78 .75 2.22 1.60 A/4L 9.25 9.00 6 Cross AFD104 2 .78 .75 2.22 1.60 A/4L 10.25 10.00 6 Cross AFD112 2 .78 .75 2.22 1.60 A/4L 10.98 10.73 6 Cross AFD124 2 .78 .75 2.22 1.60 A/4L 12.25 12.00 6 I-Beam www.fennerdrives.com NOTES: All dimensions are for rfrence only. Consult factory for availability.
-
