PWRBLADE
® CONNECTOR SYSTEM
ASSOCIATED PRODUCTS AND CAPABILITIES
PowerSupplySolutions PWRBLADE
® FCI offers PwrBlade
® cable assemblies and
industrial connectors thatare designed to mate to PwrBlade
® right-angle or verticalboard-mounted headers. By expanding beyond board-to-board
applications, designers can now connect
industrial power supplies and
power distribution subassemblies in a wider range of
applications. The combination of cable connection capability
with FCI’s proven PwrBlade
® board-to-board system providesauniversal power distribution connector system.FCI’s PwrBlade
® I/O connectors are available in squeeze-to-release form factors for applications that require active
latching and in panel-mount configurations for modular
installation of large power distribution systems. PwrBlade
® Cable Assemblies can be found on page 18.
FCI offers a wide range of power and signal PwrBlade
® cables assemblies in both squeeze-to-release andpanelmount configurations.Please go to page 20 for
more information.
FCI possesses the unique capability to integratePwrBlade
CONNECTORIZED POWER DISTRIBUTION SYSTEMS
FCI has the capability to integrate PwrBlade
® connectors intopower distribution systems that arebased on laminated bus
bars and plates that provide predictable performance and
repeatable accuracy.From simple to complex powerdistribution requirements, FCI can design a system that saves
space, lowers cost and provides pluggable modularity to allow
equipment expansion and changeovers.FCI Power Distribution systems areengineered for easyconnectivity. FCI’s expertise and wide selection of connectors
and cable assemblies makes it fast and easy to connect
power to backplanes and boards, while bus components are
matched to your physical system for easy installation and
maximum space efficiency.
® ,HCI
™ ,other power connectors or cableassemblies as a part of a BusBar Power Distribution
solution.Please go to page 18 for more information.
