PowerSupplySolutions Housing •Glass-filled high temperature nylon
•Color: BlackContacts •Power contacts: Copper based alloy
•Signal pins: Phosphor-bronze
•Signal contacts: Copper based alloyPlating •All contacts: 0.76 µm (30 µin.)
•Gold over 1.27 µm (50 µin.) nickel Product Specification: GS-12-149Application Specification: BUS-20-067
PwrBlade
® Worksheets for custom design or layout•51696 – Vertical header
•51697 – R/A header
•51698 – Vertical receptacle
•51699 – R/A receptacleContact your local FCI representative to obtain these worksheets.
ELECTRICAL PERFORMANCE
MECHANICAL PERFORMANCE TOOLING
Insulation Resistance
•Power contact: 10,000M ohms
•Signal contact: 500M ohms
Withstanding Voltage
•Power contact: 2500 volts DC
•Signal contact: 1000 volts DC
Current rating: 48 Amps for single powered contact;
de-rated to 30°C for 10 powered contacts at 30°C
temperaturerise with zeroairflow
Current rating: 60 Amps per contact per UL test guidelineswhen 10 contacts are fully energized.LLCR: <20 milliohms For Press Fit tooling contact your local FCI Sales
Representative
CERTIFICATIONS & APPROVALS
UL ,CSA and TUV approved
PACKAGING
Trays Mating force: •25 ounces per Power Contact
•3.5 ounces per Signal Contact
