SOFIX
® MATERIALS APPROVAL & CERTIFICATIONS
PRODUCT SPECIFICATION
Plug• Housing: Polybutylene Terephthalate (PBT UL94 V-0)
• Terminals: Copper Alloy
• Covers: Zinc AlloyHeader• Housing: Liquid
Industrial crystal Polymer (UL-94 V-0)
• Terminals: Copper Alloy
• Covers: Zinc Alloy
•
Ground spring: Stainless Steel Underwriters Laboratories Inc. (UL file no. E66906)Canadian Standards Association (CSA file no. LR46923)
PERFORMANCEMECHANICAL CHARACTERISTICS
Per Telcordia GR1217-CORE, Central Office requirements Header: GS-12-307Cable Connector: GS-12-308
Recommended Cable specification: • Copper 2.5mm
2 • Overall Ø 1.95mm
• Total diameter Ø 8.0mm max. Packaging Specification: GS-14-1093 Insertion force: 20 N max Durability: 200 cycles (Telcordia)
Temperature Range: -40°C to +70°C
ELECTRICAL CHARACTERISTICS PACKAGING
Current rating: 10 A per contactWithstanding voltage: 1000 V RMS Initial Insulation resistance: 5000M Ω minimum. Headers: Tubes
Header accessories: Bags
Cable Connector components: Bags
Power I/O Solutions PART NUMBERS
DescriptionPart Number Header Right Angle with 15 Amp filter72846-204LFCable connector kit72824-201LF
Contact your local FCI sales representative for cable assemblies
www.fciconnect.com/sofix
