DESCRIPTION
The USB + Power interconnect system was developed by FCI to address higher power requirements of devices using USB signaling. USB + Power adds 4 power contacts to the interface providing a total of 5 amps of additional current carrying capability compared to 1 amp for standard USB. For many devices, this eliminates the requirement for a separate power source reducing the number of cables required. For peripherals not requiring the additional current, the USB + Power receptacle will mate with a standard USB 'A' plug.
To insure proper mating, USB + Power is individually keyed and color coded for 5V, 12V, and 24V.
FEATURES & BENEFITS
Provides up to 5 amps of current carrying capacity eliminating the need for an external power supply in most peripheral devices
Receptacle mates with standard USB 'A' plug
Keyed and color coded for different voltages
Positive latching insures proper mating and retention
Fully shielded providing USB 2.0 data
performance
Hot plugging capability
TARGET MARKETS / APPLICATIONS
Data
Consumer
Datacom/Telecom
PC
Point of sale
Hubs
Speakers
24
