SPECIFICATIONS
Power Contact Base Material• Brass alloyBoard Connector and Cable Connector Housings• High temperature nylonPlating• Minimum 0.8 um Au over minimum 1.27um Ni inthe contact area• Minimum 2um Tin on crimping area Product Specification: GS-12-389
Packaging Specification: GS-14-1093
CERTIFICATIONS & APPROVALS
UL 1977
Touch-proof per IEC 60998-1 and IEC60668-2
ELECTRICAL PERFORMANCE PACKAGING
100 Amps per twin contact at 75°C ambient
Operating Voltage: 80 Volts DC at 25 Amps Short Circuit Capacity: 5 operations carrying 3000 Amps
for 10ms Insulation Resistance: 1G Ω when measured in accordancewith EIA 364 TP 21
Connector Rating: 2kW. 100A@20V to 25A@80V Trays
MECHANICAL/ENVIRONMENTAL PERFORMANCE
Insertion Force: shall not exceed 40N
Withdrawal Force: shall not be less than 15N
Durability: 50 cycles
Operating Temperature Range: -20°C to +75°C
Power I/O Solutions PART NUMBERS
DescriptionPart Number Right Angle Entry Cable Connector10056526
Straight Entry Cable Connector10066104
Right Angle Board Connector51939-219 Reference the product drawings to obtain detailed dimensions and complete part numbers.
Contact your local FCI sales representative for cable assemblies
www.fciconnect.com
21
MATERIALS
