I/O CABLE ASSEMBLIES
DESCRIPTION
The Pwr TwinBlade
™ cable system isdesigned to support applications that
demand the supply of high power. The Pwr
TwinBlade
™ industrial connectors employ a provencontact system in a touch-proof design that
is capable of supporting currents of up to
100 Amps per twin contact. The system
consists of cable connectors in orientations
of right angle or straight cable exits matingto a right angle board connector. Other connector features include an activelatch, four different coding options andpolarization to ensure proper mating. Thedesign provides capability for termination of various cable diameters and wire sizes of
6 AWG. FCI is able to provide the industry
with component cable kits as well as cable
assemblies terminated with Pwr TwinBlade
™ connectors.
FEATURES & BENEFITS TARGET MARKETS
Modular system provides right-angleand straight cable connectors
Right-angle board connector enables front I/O applicationsRobust, touch-proof connector designFour different cable-entry directions
possibleActive latching system
Polarized design ensures proper mating
Four coding options
Supports multiple wire sizes Communications• Wireless base stations
• aDSL/ vDSL Access equipmentData• Industrial servers
• Storage
