PWRBLADE
® ORIENTATION
Housing• Glass-filled high temperature nylon
• Color: BlackContacts• Power contacts: Copper based alloy
• Signal pins: Phosphor-bronze
• Signal contacts: Copper based alloyPlating• All contacts: 0.76 µm (30 µin.)
• Gold over 1.27 µm (50 µin.) nickel Squeeze-to-Release latchingFloating Blind-Mate Panel-Mount
TERMINATION
Power: 8 AWG, 10 AWG, 12 AWG
Signal: 22 AWG, 24 AWG, 26 AWG
ELECTRICAL PERFORMANCE
Ω max. at rated power
SPECIFICATIONS
Insulation resistance: 20M Ω min.Withstanding voltage: 1,200 V RMSCurrent rating: 48 A for single powered contact; de-rated
to 30A for 12 powered contacts at 30°C temperature rise
with zero airflow
Current rating: 60A for 10 contacts when tested to UL
guidelines.Contact resistance: 0.5m Product Specification: GS-12-149Application Specification: BUS-20-067
Packaging Specification: GS-14-1093
MECHANICAL PERFORMANCE CERTIFICATIONS & APPROVALS
Mating force: 12 lbs. typical for 11 power, 24 signalconfiguration UL ,CSA and TUV approved
Power I/O Solutions Contact your local FCI sales representative for cable assemblies
www.fciconnect.com/pwrblade
19
MATERIALS
