METRAL

®

POWER CONNECTORS TECHNICAL INFORMATION

MATERIALS ELECTRICAL CHARACTERISTICS

Housing: Liquid Industrial crystal Polymer (UL-94 V-0)Terminal: Phosphor Bronze Plating:• Separable interface: Gold or GXT Current rating: 3 Amps nominal (4 Amps Max) current per contactWithstanding Voltage: 1000 VACInsulation resistance: > 5000M Ω (> 1000M Ω
™ after environmental exposure) • Solder tails: Tin over Nickel • Press-fit: Tin over Nickel and Tin-Lead over Nickel

PERFORMANCE APPROVALS AND CERTIFICATIONS

Per Telcordia GR1217-CORE, Central Office requirements
Backplane-to-Card Solutions Underwriters Laboratories Inc. (UL file no. E66906)Canadian Standards Association (CSA file no. LR46923)

MECHANICAL CHARACTERISTICS PACKAGING PART NUMBERS

Insertion force: 1.5 N max per individual contact Withdrawal force: 0.3N min per individual contact Durability: 200 cycles (Telcordia) Temperature: -55°C to +105°C Headers Vertical: TubeHeaders Right Angle: TrayReceptacles Right Angle: Tube DescriptionTerminationBase Number4 Rows (8 contacts) 5 Rows (10 contacts) Header, verticalPress-fit7023689099 Header, right-anglePress-fitHM1K41HM1K51 Receptacle, right-anglePress-fit8894989096 Receptacle, right-angleSolder8903985876 Receptacle, verticalSolder9323994561

www.fciconnect.com/metral

17
