| | | MATERIALS Contact Base Metal: Copper Alloy Contact Finish • Gold over nickel on separable interface • Tin-lead over nickel on press-fit tails Housing: High temperature thermoplastic (UL 94V-0) | | SPECIFICATIONS Product Specification: GS-12-220 Application Specification: GS-20-023 Safety: UL 60950 & IEC 60950-1 Prevention of Operator Access to Energized Parts | | |
| | | MECHANICAL PERFORMANCE Durability: 100 mating cycles Mating force: 31.2N maximum per 1x2 or 2x2 module Unmating force: 9.0N minimum per 1x2 or 2x2 module Press-fit insertion force: 67N maximum per individual contact tail ELECTRICAL PERFORMANCE Voltage rating: 150V DC Contact Resistance: 1.0mQ maximum Current Rating: Maximum amps per contact for different header and receptacle test configurations with dual (double sided) external copper pads of noted weight | | ENVIRONMENTAL Per Central Office requirements, Telcordia GR-1217-CORE APPROVALS AND CERTIFICATIONS Per Central Office requirements, Telcordia GR-1217-CORE | | |
