| | | POWER CARD EDGE | | |
| | | |
| | | TECHNICAL INFORMATION | | |
| | | |
| | | MECHANICAL PERFORMANCE Durability: 200 mating/un-mating cycles Insertion force for an add-in board: • Right-angle: 13.62 kg maximum • Vertical or straddle-mount: 8.0 kg maximum Operating temperature range: -5°C to +105°C | | TI o (D | | |
| | | MATERIALS Housing: high-temperature thermoplastic (UL94V-0), black Contact base metal: • Power - high-conductivity copper alloy • Signal - copper alloy Contact area finish: gold over nickel Solder area finish: matte pure tin over nickel | | |
| | | |
| | | UÌ c 73 1 < | | |
| | | |
| | | |
| | | |
| | | SPECIFICATIONS Right-Angle Product Specification: GS-12-259 Vertical Product Specification: GS-12-338 Straddle-Mount Product Specification: GS-12-279 | | |
| | | ELECTRICAL PERFORMANCE Current rating: 7A/power contact measured at 30°C temperature rise in still air Insulation resistance: 5000 MQ minimum for power contact Withstanding voltage: 1000V AC for power contact Contact resistance: • Right-angle: 55 mQ maximum • Straddle-mount: 20 mQ maximum • Vertical: 20 mQ maximum | | |
| | | |
| | | APPROVALS AND CERTIFICATIONS UL ,CSA and TUV approved | | |
| | | |
| | | |
| | | PACKAGING Trays | | |
| | | |
| | | PART NUMBERS | | |
| | | |
| | | Right Angle Solutions Description Base Number | | |
| | | |
| | | | | | | | | | 5 power + 12 signal + 5 power | | | | | 7 power + 12 signal + 7 power | 10028886 | | | | 10 power + 12 signal + 10 power | | | | 14 power + 12 signal + 14 power | | | | | With AC Power port | 10055090 | | | | 2x14, 2x17, 2x22, 2x25, 2x28, 2x29, 2x31, 2x32 power | 10035388 | | | | Vertical Solutions | | | | | Description | Base Number | | | | 2x19, 2x31, 2x32, 2x35 power | 10046971 | | | | 2x8 power | 10046972 | | | | Straddle-Mount Options | | | | | Description | Base Number | | | | 2x19, 2x23 power | 10034908 | | | | | | | | | |
| | | |
| | | Use the base numbers to reference the product drawings to obtain detailed dimensions and complete part numbers. | | |
| | | |
| | | bovver i Solutions 11 | | |
| | | www.fciconnect.com/powercardedge | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
