| DESCRIPTION The Power Card Edge connector is a cost-effective connector system that can be used for DC power output from embedded AC/Dc power supplies or for power distribution between boards within an enclosure. The connector range includes options for right-angle, vertical, or straddle-mount solder termination. The connectors manufacturer' low profiles are ideal for use in enterprise data or communications equipment, particularly in industrial servers and external storage systems. The width of the Power Card-Edge connector body is 9mm or less, making it well-suited for use in 1U rack-mount servers or on power distribution boards inside 1U redundant power supply assemblies. The low connector profile helps maximize airflow through a power supply for increased cooling. Adjacent power contacts are positioned on 2.54mm pitch along the card edge. Power contacts are manufactured using a high-conductivity copper alloy. Each power contact is rated for up to 7A current measured at 30°C temperature rise in still air. Signal contacts are positioned on 1.27mm pitch. Right-angle, vertical and straddle-mount connectors are available in various circuit counts with a full complement of power contacts. Right-angle connector options also include versions that combine power and power control signal contacts or power contacts and an integrated AC pass-through port in a single connector. |
