| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | 0.3MM CONTACT SPACING | | | | | | | | | | sfyl series - 10013057, 10017251 | | | | | | | | | | Orientation: Right Angle Cable termination: Non-ZIF Cable type: FFC/FPC Board termination: Surface mount Contact location: Upper and lower available Height: 1.2mm Lead free with gold plating Accommodated cable thickness: 0.2mm Front flip type actuator makes cable application easy and error free Very low profile for maximum space savings | | | | | | | | | | | | | | | | | Part Number | Number of Positions Available | | | | Upside Contact | | | | | 10017251-xx2240ELF | 11,15,19,23,25,27,31,39,45,51 | | | | Downside Contact | | | | | 10013057-xx1200ELF | 17,21,25,29,31,35,45 | | | | | | | | | | | | | | | | | sfy series - 62789 | | | | | | | | | | Orientation: Right Angle Cable termination: ZIF with prehold Cable type: FFC/FPC Board termination: Surface mount Contact location: Lower Height: 2.0mm Lead free with gold plating Surface mount termination Accommodated cable thickness: 0.2mm Front flip type actuator makes cable application easy and error free Economical fine pitch flex connector | | | | | | | | | | Part Number | | Number of Positions Available | | | | | | | | | | 62789-xx1111ALF | | | | | | 27,45,51,57,67 | | | | | | | | | | | | | | xx - Number of Contacts | | | | | | | | | | www.fciconnect.com/flex | | | | | | 6 | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
