1.0MM CONTACT SPACING SLW SERIES
Orientation: Right angle and verticalCable termination: ZIF with prehold
Cable type: FFC/FPC/CIC
Board termination: Through hole Contact location: Lower
Height: 4.0mm right angle, 5.5 vertical
Lead free plating availableVersatile, economical connector system withuses in many applications Part Number Number of Positions Available SLWxxR-1C7LF4-30 OrientationCable Type R-Right angle1-FFC/FPC
S-Straight5-CIC
HLW SERIES
Orientation: Right angle or verticalCable termination: Non-ZIFCable type: FFC/FPC/CICBoardtermination: Through hole Contact location: Upper
Height: 3.9mm right angle, 5.9 vertical
Lead free plating availableThrough hole alternativeEconomical connector system Part Number Number of Positions Available HLWxxR-2C7LF4-32 OrientationCable Type R-Right angle2-FFC/FPCS-Straight6-CIC xx - Number of Contacts
14
www.fciconnect.com/flex
