1.0MM CONTACT SPACING HFW SERIES
Orientation: Right angle and vertical optionsCable termination: Non-ZIF
Cable type: FFC/FPC/CIC
Board termination: Surface mount Contact location: Upper and lower options
Height: 1.9mm right angle, 5.3 vertical
Lead free with gold platingVersatile, economical connector system withuses in many applications Part Number Number of Positions Available HFWxxR-1STE1Right angle 4-33Vertical 4-30 Packaging R-Right angle
S-Straight Right Angle Contact/Cable Type Orientation E1-tape and reel 2000 piecesRight Angle
1-FFC/FPC downside contactVertical
2-FFC/FPC upside contactE1-tape and reel 1000 piecesVertical2-FFC/FPC
6-CIC Mounting ST-SMT
STM-SMT with tab (vertical only) xx - Number of Contacts
www.fciconnect.com/flex
13
