| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | 0.5MM CONTACT SPACING | | | | | | | | | | sfve series - 10054365 | | | | | | | | | | Orientation: Right Angle Cable termination: ZIF Cable type: FFC/FPC Board termination: Surface mount Contact location: Upper Height: 1.2mm Lead free with gold plating Accommodated cable thickness: 0.2mm Front flip type actuator makes cable application easy and error free | | | | | | | | | | Part Number 10054365-xx2110ELF | | Number of Positions Available 18,20,28,30 | | | | | | | | | | | | | | opu series - 62684 | | | | | | | | | | Orientation: Right Angle Cable termination: ZIF with prehold Cable type: FFC/FPC Board termination: Surface mount Contact location: Uupper and lower options Height: 2.0mm Lead free with gold plating Accommodated cable thickness: 0.3mm Economical higher pin count flex connector solution Traditional sliding actuator secures cable | | | | | | | | | | | | | | | | | Part Number | Number of Positions Available | | | | Upside Contact | | | | | 62684-xx2100ALF | 32,34,36,40,43,45,50,55,57 | | | | Downside Contact | | | | | 62684-xx1100ALF | 38,40,45,50,57,60 | | | | | | | | | | | | | | | | | xx - Number of Contacts | | | | | | | | | | www.fciconnect.com/flex | | | | | | 10 | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
