MAIN PRODUCTSPART REFERENCES

SERVER SYSTEM INFRASTRUCTURE (SSI STANDARD)Distributed Power Supply (1 Power + 24 Signal + 1 Power Configuration)Tin/LeadLead-Free ServerRight Angle Receptacle 51416-001 51416-001LF Vertical Press-Fit Receptacle 51666-001 51666-001LF Power SupplyRight Angle Header 51415-001 51415-001LF Vertical Header 51952-001 51952-001LF Vertical Press-Fit Header51952-002 51952-002LF High-End Power Supply (12 Power + 24 Signal Configuration)Tin/LeadLead-Free Server Vertical Receptacle 51261-XX001 51261-XX001LF Vertical Press-Fit Receptacle 51617-XX002 51617-XX002LF Power SupplyRight Angle Header 51219-XX002 51219-XX002LF Mid-Range Power Supply (6 Power + 24 Signal + 5 Power Configuration)Tin/LeadLead-Free ServerRight Angle Receptacle 51625-XX001 51625-XX001LF Vertical Press-Fit Receptacle 51667-XX001 51667-XX001LF Power SupplyRight Angle Header 51624-XX001 51624-XX001LF Vertical Header 51860-001 51860-001LFVertical Press-Fit Header 51860-002 51860-002LF AC CABLE PORT RIGHT ANGLE RECEPTACLE Power+Signal+Power+Cable 51894-YYY 51894-YYYLF Power+Cable 51919-YYY 51919-YYYLF Signal+Power+Cable 51921-YYY 51921-YYYLF Power+Signal+Cable 51923-YYY 51923-YYYLF AC CABLE PORTVERTICAL RECEPTACLE Power+Signal+Power+Cable 51897-YYY 51897-YYYLF Power+Cable 51925-YYY 51897-YYYLF Signal+Power+Cable 51927-YYY 51927-YYYLF Power+Signal+Cable 51929-YYY 51929-YYYLF
Note: The XX and YYY utilized in the part numbers above are placeholders for certain product specific criteria.Reference the product drawings to obtain detailed dimensions and complete part numbers. For non-SSI applications other configurations are available upon request. Further information can be found at:http://www.fciconnect.com/pwrblade

47
