USB

UNIVERSAL SERIAL BUS

FEATURES

USB 2.0 compliant, speed to 480 Mb/sec

Type A (Host) receptacles, 4 position

- Through hole and SMT versions

- PCB mount options: Position, orientation, hold-down.

- Panel fixing and grounding options

- Additional sensor contact versions

- Double deck, 8 position version Type B (peripheral) receptacles,

4 position

Mini USB receptacles, 5 position Plug kits for overmold cable assembly manufacturer USB + power versions available

APPLICATIONS

Industrial computers, laptops, industrial servers Printers, external drive units, industrial monitors Industrial digital cameras, TV's, set-top box Modems, industrial keyboards, industrial instrumentation Point-of-sale equipment.

MAIN PRODUCTS PART REFERENCES

Type A Rec. right angle TMT_87520 / 73725 / 74552


	Rec. right angle SMT	87583 / 74626
	Rec. small body TMT	52319

Double Deck. 72309 / 52454


	Type B	Rec. right angle TMT	61729
	Mini B	Rec. right angle SMT	10033526
	Mini AB	Rec. right angle SMT	10033527
	Type A	Plug, straight	74033
	Type B	Plug, straight	61730
	Type A	USB+Power Rec.	55917 / 57489 / 10011029
		USB+Power Plug	74233/57496

¥1 fsl 1*

Further information can be found at: http://www.fciconnect.com/usb

37
