| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | SAS SERIAL ATTACHED SCSI | | | | | | | | | | FEATURES 29-position SAS receptacle and plug connectors enable the high-speed, Serial Attached SCSI (SAS) hard disk drive (HDD) interface that is replacing the SCSI designed to support differential signaling, initially at speeds of 3 Gb/s and evolving to 6 Gb/s Connectors conform to SFF-8482 Provide dual signal ports (7 contacts/ port) and 15 contacts for power SAS receptacles also accept SATA drives Designed to support hot-plugging and blind-mating of HDDs Connector retainers provide additional mechanical strength after soldering RoHS-compliant and compatible with lead-free processing temperatures | | APPLICATIONS Data Server and storage blades External storage systems HDDs HDD carriers Communications Embedded system boards | | | | | | | | | | | | | | | | | | | | | | MAIN PRODUCTS | | PART REFERENCES | | | | Drive Device Plug | Straddle Mount | 10054761 | | | | | | Contact FCI for customization | | | | Adapter Plug | Vertical, SMT | 10031193 | | | | Vertical, SMT (With Rivet Holes) | 10045105 (Also: see SATA 10045103) | | | | Right-angle, SMT | 10034524 | | | | Host Receptacle | Vertical, Wide Base, Hybrid Footprint | 10036876 | | | | Vertical, Wide Base, Thru Hole | 10039748 | | | | Vertical, Press Fit | 10031077 | | | | Vertical, Wide Base, SMT | 10039845 | | | | Vertical, SMT | 10031567 | | | | Vertical, Wide Base, Press Fit | 10038064 / 10045782 | | | | Right-Angle, SMT | 10035202 | | | | Right-Angle, SMT, Reversed | 10036587 | | | | Right-Angle, High Rise, SMT | 10044002 | | | | 4 Lane Internal Plug | Vertical, Press Fit | 10028542 | | | | Vertical, SMT | 10045646 | | | | Vertical, Thru Hole | 10044625 | | | | Vertical, Thru Hole (Half-Moon Peg) | 10053670 | | | | 4 Lane External I/O | | See FCI EyeMax family - thumbscrew version | | | | | | | | | | | | | | | | | | Further information can be found at: http://www.fciconnect.com/sas | | | | | | 28 | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
