BOARD-TO-BOARD CONNECTORS MANUFACTURER

CARD EDGE CONNECTORS

FOR MICRO TCA

™

APPLICATIONS

FEATURES

FCI connectors are in full compliancewith the MicroTCA standard developed within PICMG
® Designed to enable AdvancedMC™ (AMC™) modules to plug directly to a backplane 170 position card edge interface with 0.75mm contact pitch Options for press-fit or surface-mount (SMT) termination Metal retention clips at ends of SMT connector provide additional mechanical strength after soldering Very low loss and crosstalk for low- voltage differential signaling at data rates up to 12.5 Gb/s per lane SMT footprint allows for increased flexibility in routing PCB traces Telcordia UE compliant Lead-free and RoHS-compatible

APPLICATIONS MAIN PRODUCTSPART REFERENCES

Telecommunications Datacommunications Termination style Surface Mount10058835 Radio Base Stations RF antenna units IP gateways Enterprise switches Customer premises equipment (CPE) Press Fit10058831 Additional support materials SPICE modelsvisit fciconnect.com 3D view modelsvisit fciconnect.comTest back planescontact FCI
PICMG ® , AdvancedMC™, AMC™, and MicroTCA™ are trademarks of the PCIIndustrial Computer Manufacturers Group. Further information can be found at:http://www.fciconnect.com

26
