| FEATURES Support convenient, add-on memory expansion with standard memory module assemblies Connectors provide mechanical voltage retention and ejection. DDR2 FB-DIMM connectors accept module assemblies that conform to JEDEC MO-256 DDR2 DIMM connectors accept assemblies that conform to JEDEC MO- 237. 240-position FB-DIMM and DIMM connectors feature a low insertion-force socket design that requires less than 24 pounds force for module installation. Available solder tail options for vertical DDR2 DIMM connectors support use on 1.58mm (.062") or 2.36mm (.093") thick industrial motherboards, while press-fit options extend use to thicker motherboards. Contact design protects against stubbing and supports high-speed serial differential signaling at data rates extending to 4.8 Gb/s for FB-DIMM. DDR2 SO-DIMM connectors offer keying options for standard and reverse module orientation. The 200-postion horizontal sockets accept modules that conform to JEDEC MO-224. RoHS-Compliant and "Lead-free" process-compatible options are available to aid compliance with lead elimination initiatives. |
