| | | | | | | | | | | | | | | | | | | | | | | | | | | | | FLOATING BOARD-TO-BOARD | | | | | | | | | | FEATURES BTFN (1.25 mm pitch) and BTFW (1.0 mm) Surface mount and Through mount versions Straight and Right Angle versions Reliable mechanical performance due to wide floating allowance (in pitch, width and Z direction) Easy handling due to rigid guiding design | | | | | | | | | | APPLICATIONS Consumer Electronics: e.g. Automobile AV systems and navigation systems, Automobile CD and MD players, including chargers, VCRs, DVD and CD players, Set-top boxes, Satellite tuners Computer Peripherals: CRT and Industrial lcd monitors | | | | | | MAIN PRODUCTS | | SERIES* | | | | | | | | | | | | | | | | | | | BTFN | Plug | Right Angle, Through Hole | BTFN | | | | | | Right Angle, Through Hole & Mounting Latch | BTFN | | | | | Receptacle | Vertical, Through Hole | BTFN | | | | | | Vertical, SMT | BTFN | | | | BTFW | Plug | Vertical, SMT | BTFWXXP-3SSTE1LF | | | | | Receptacle | Vertical, SMT | BTFWXXR-3SSTE1LF | | | | | | Right Angle, SMT | BTFWXXR-3RSTE1LF | | | | | | Right Angle, Through Hole | BTFWXXR-3RD7LF | | | | | | | | | | | | | | | | | | | | | | | "XX" is a placeholder for the number of positions | | | | | | | | | | Further information can be found at: http://www.fciconnect.com/boardmate | | | | | | 23 | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
