| | | RIB-CAGE™ | | |
| | | |
| | | FEATURES fck Exclusive Rib-Cage™ multi-point | | |
| | | |
| | | receptacle contacts provide optimal reliability in high vibration and shock-prone applications. High density 1.27mm (.050 in.) x 1.27mm (.050 in.) system for connecting parallel PCBs Multiple stack height options Polarization option prevents mis-mating Surface mount and through-hole attachment options | | |
| | | |
| | | APPLICATIONS Shock resistant and vibration-resistant electronics Electronic subassemblies attached to motors, industrial fans and mechanical devices | | |
| | | MAIN PRODUCTS Headers Vertical Surface Mount | | PART REFERENCES 87409 / 90098 / 87849 / 93221 | | |
| | | |
| | | |
| | | Right Angle Through Hole | | |
| | | 87402 | | |
| | | |
| | | |
| | | Receptacles | | Vertical, Surface Mount | | 87021 / 87022 / 87023 / 87024 | | |
| | | |
| | | |
| | | |
| | | |
| | | Reference to data sheet: 950521-010 | | |
| | | |
| | | Further information can be found at: http://www.fciconnect.com/ribcage | | |
| | | 21 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
