FEATURES APPLICATIONS
Suitable for FFC / FPC / CIC cable0.30 - 0.40 - 0.50 - 1.00 - 2.54 mmpitch sizesHighly reliable Gas Tight High pressure(GTH) contact systemZero Insertion Force (ZIF) and LowInsertion Force (LIF) optionsStraight and Right-Angle versions
Surface Mount and Through Hole LC Display to Board connections
Interior Automotive electronics
Membrane Switches
DVD / HDD connection Mobile phone and
Industrial digital camera MAIN PRODUCTSPART REFERENCES
TYPEORIENTATIONSERIESCONTACT LOCATON
0.3 mm Pitch ZIF/LIFSMT Right angleSFYLower62789 Right angle SFYLLower10013057 Right angle SFYLUpper10017251 Right angle YLLLower10061122 Right angle YLLUpper10064555 0.4 mm Pitch ZIF SMTRight angle GLHLower10051806 0.50 mm Pitch ZIFSMTRight angle SFVLUpper or Lower59453 Right angle SFVUpper or LowerSFVxxR StraightSFV-S62674 Right angle OPUUpper or Lower62684 Right angle SFVAUpper and Lower10014265 Right angle VLLLower10051922 Right angleVLHLower10042867 1.00 mm Pitch ZIFSMT Right angleSFWUpper or LowerSFWxxR StraightSFWSFWxxS Non-ZIFSMTRight angleHFWUpper or LowerHFWxxR StraightHFWHFWxxS ZIFDIP Right angleSLWUpper or LowerSLWxxR StraightSLWSLWxxS Non-ZIFDIP Right angleHLWUpper or LowerHLWxxR StraightHLWHLWxxS 2.54 mm Pitch Duflex contacts and housings76785 / 67013 / 66987Clincher pre-assembled snap-shut system 66226 / 65801/10027313/ (mates to PCB headers)10022753/67516 / 67368
Shrouded PCB headers for 2.54 mm Clincher
™ receptacle95735 / 95736 Further information can be found at:http://www.fciconnect.com/flex
