BOARD-TO-BOARD / WIRE-TO-BOARD INDUSTRIAL CONNECTORS
BERGSTIK® / DUBOX™ / QUICKIE® / PV®
2.54 MM MODULAR SYSTEM
FEATURES
Versatile 2.54 mm modular system includes board-to-board, wire-to-board and flat cable interconnects, offering complete design flexibility Range: 1x2 to 2x36 positions Selective plating is reliable and economical
Easy part number selection at FCI Basics+ web site
Bergstik unshrouded headers available in custom configurations
APPLICATIONS
Electronic equipment or devices requiring a parallel, planar or perpendicular board-to-board, wire-to-board or flat cable interconnects Uses span industry segments (e.g. base stations, measuring equipment, industrial control)
Further information can be found at: http://www.fciconnect.com/basics http://www.fciconnect.com/bergstik http://www.fciconnect.com/dubox http://www.fciconnect.com/quickie
14
