BACKPANEL INDUSTRIAL CONNECTORS

MILLIPACS

®

HARD METRIC 2 MM CONNECTORS

FEATURES

Modular system with 5+2 row and8+2 row high density connectorsDesigned in accordance with IEC 917and IEC 61076-4-101 as well as CompactPCIHard metric board and cableconnector offeringExtended functionalities: staggeredcontacts, shielding, keying, guiding, power and coax inserts, shrouds.

APPLICATIONS MAIN PRODUCTSPART REFERENCES

Switches, base stations, embeddedcomputers, medical testing, PLC’s.All applications requiring high densityconnections BOARD CONNECTORS 5 rowstraight headersr/a receptaclesrear shrouds Type AHM2P07HM2R01/HM2R10HM2H07 Type BHM2P08HM2R02HM2H08 Type B22HM2P70HM2R70HM2H70 Type B19HM2P71HM2R71HM2H71 Type ABHM2P65HM2R65HM2H65 Type AB22HM2P66HM2R66HM2H66 Type AB19HM2P67HM2R67HM2H67 Type CHM2P09HM2R03/HM2R30HM2H09 Type CRHM2P80HM2R20/HM2R21HM2H80 Type LHM2P10HM2R04 Type MHM2P11HM2R05/HM2R50Type NHM2P12HM2R06 Further information can be found at:http://www.fciconnect.com/millipacs

12
