Maximum Diameter (0) mm	Head Thickness Mild Steel mm	Head Thickness Stainless mm	F longer Size /Dia	Recomended press Press/D	Manipulator Capacity
3000-4000	6	4	BF6/D	PPM 100/D	MA 15
3000-4000	10	7	BF 10/D	PPM 150/D	MA 15
3000-5000	15	!0	BF 15/D	PPM 200/D	MA 30
4000-5000	18	12	BF 18/D	PPM 220/D	MA 50
4000-5000	20	14	BF 20/D	PPM 250/D	MA 50
4000-5000	22	16	BF 22/D	PPM 280/D	MA 70
4000-6000	25	18	BF 25/D	PPM 300/D	MA 70
4000-6000	28	20	BF 28/D	PPM 350/D	MA 70
4000-7000	30	22	BF 30/D	PPM 400/D	MA 70
4000-7000	32	25	BF 32/D	PPM 500/D	MA 70
4000-8000	36	28	BF 36/D	PPM 600/D	MA 120
5000-9000	40	30	BF 40/D	PPM 800/D	MA 200
5000-9000	42	31	BF 42/D	PPM 900/D	MA 240
5000-9000	45	32	BF 45/D	PPM 1000/D	MA 240

Quality without compromise

Each model of machine is available in different dimensions according to tlte heads maximum diameter Larger, Smaller and intermediate sizes are available upon request.

Please always complete your enquiry with the indication on the types of head you need to manufacture.
