| | | Pancake® Cylinders 1 1/8" (121) Bore Model Number | | |
| | | |
| | | Prefix Options | | Stroke | | Bore | | Action | | Suffix Options | | |
| | | Model Number Code | | |
| | | 1 | | |
| | | |
| | | |
| | | Leave blank if none desired | | |
| | | MR | | |
| | | |
| | | |
| | | |
| | | |
| | | | | | | | | | Bore | Code | | | | 1 1/8" | 121 | | | | 28.5mm | 121 | | | | | | | | | |
| | | Metric M See pages 1.7, 1.31 & 1.34 | | |
| | | |
| | | |
| | | | | | | | | | Suffix Options | | | | | Male rod thread: Single rod Double rod, rod end Double rod, cap end Double rod, both ends | -MR -MR -MR1 -MR2 | | | | PTFE seals | -T | | | | Viton seals | -V | | | | Quad seals | -Q | | | | External guide, nonrotating for load guiding (See page 1.65) | -G | | | | Hydraulic: Standard cover | -H | | | | Hole thru double rod shaft: 1/8" hole Plus size: 5/32" hole 150 psi max | -13 -16 | | | | Finish: ProCoat™ (Electroless Nickel) | -N | | | | Stroke collar: 1/8" 1/4" -C2 3/8" 1/2" -C4 5/8" 3/4" -C6 7/8" | -C1 -C3 -C5 -C7 | | | | Sound limiters: Rod end Cap end Both ends | -LF -LR -LFR | | | | Rubber Bumpers: Rod end Cap end Both ends | -BF -BR -BFR | | | | Adjustable extend stroke (Full stroke adjustment is standard) | -AS | | | | Adjustable retract stroke (Over 1" adjustment add desired length, e.g. -RS2) | -RS | | | | Clevis mount: Ports in-line with slot Ports 90° to slot | -PM -SM | | | | Eye mount: Ports in-line with tang Ports 90° to tang | -EPM -ESM | | | | Threaded nose mount: Single rod Double rod, rod end Double rod, cap end Double rod, both ends | -F -F -F1 -F2 | | | | Magnetic piston & sensor mounting slot(s) Order sensors separately. See page 1.14. Stroke length determines number of mounting slots. See page 1.14, 1.32, 1.34 | -E | | | | See pages 1.3 - 1.15 for general option information and pages 1.31, 1.32 & 1.34 for option specifications of 1 1/8" bore models. | | | | | | | | | |
| | | | | | | | | | | | Standard Strokes | | | | | Original Series | | | | Action | X | | | | | | | XK | O | | | | | | XDR | | | | | | | XDRK | ODR | OP | | | | Stroke | | | | | | | 1/8 | A | A | A | | | | 3/16 | B | B | B | | | | 1/4 | C | C | C | | | | 1/2 | D* | D | D | | | | 3/4 | X | X | X | | | | 1 | E | E | E | | | | 1 1/4 | F | F | F | | | | 1 1/2 | G | G | G | | | | 1 3/4 | H | H | - | | | | CM | I | I | - | | | | 3 | J | - | - | | | | 4 | K | - | - | | | | "T" Series | | | | | Includes | PTFE I | | | | piston bearing 1 | | | | | X | | | | | | Action | XK | O | OP | | | | Stroke | | | | | | | 1/16 | TB | TB | TB | | | | 1/8 | TC | TC | TC | | | | 3/8 | TD* | TD | TD | | | | 5/8 | TX | TX | TX | | | | 7/8 | TE | TE | TE | | | | 1 1/8 | TF | TF | TF | | | | 1 3/8 | TG | TG | TG | | | | 1 5/8 | TH | TH | - | | | | 1 7/8 | TI | TI | - | | | | 2 7/8 | TJ | - | - | | | | 3 7/8 | TK | - | - | | | | | | Grey shading | | | | indicates sensors are | | | | | not available. | | | | | Strokes are NOT af- 1 | | | | fected by magnetic \ | | | | piston Option "E" | | | | | | | | | | | | |
| | | | | | | | | | Action | | | | | Single rod | | | | | Double acting | -X | | | | Double acting, Nonrotating Internal guide pins - 150 psi max | -XK | | | | Single acting, spring retracted | -O | | | | Single acting, spring extended | -OP | | | | Double rod | | | | | Double acting | -XDR | | | | Double acting, Nonrotating Internal guide pins - 150 psi max | XDRK | | | | Single acting, spring retracted | -ODR | | | | See pages 1.5 & 1.6 for Action Information. 1 See pages 1.30 & 1.33 for Standard Specifications 1 | | | | | | | | | | | | | |
| | | |
| | | HOW TO ORDER 1. Under Stroke - select letter(s) for desired Series and Stroke. 2. Under Bore - select 121 for 1 1/8" bore. Seven Other Bore Sizes are Available Bore Bore Code See page | |
| | | |
| | | 51.17 71.23 ------------221 ---------------1.35 | | |
| | | 1 5/ | | |
| | | |
| | | |
| | | 2"3211.41 2 1 /2"5211.47 3"7211.53 4"12211.59 3. Under Action - select letter(s) for desired action. 4. Under Prefix & Suffix Options- select letter(s) for desired options and add to model number. EXAMPLES D-121-X Original Series, 1/2" stroke - 1 1/8" Bore -Single Rod, Double Acting TD-121-X-MR "T" Series, 3/8" Stroke - 1 1/8" Bore -Single Rod, Double Acting - Male Rod Thread | | |
| | | |
| | | | | |
| | * Note - Sensors not available: _ | |
| | | |
| | | D-121-XK, TD-121-XK, D-121-XDRK A complete library of cylinder CAD drawings is available from your local Fabco-Air Distributor or from the Fabco-Air web site - http://www.fabco-air.com | | |
| | | |
