Filter - Regulator - Lubricator

with two “L” Type Mounting Brackets FABCO-AIR

, Inc.

? 3716 N.E. 49th Avenue ? Gainesville, FL 32609 ? Tel (352) 373-3578

“T” Ported Interfaceavailable - see page 22 Optional 3-way lockout/tagoutvalve shown. See page 23. Plastic bowl guards are standard for all models L-Type mounting bracketsstandard with FRLs.Regulators feature square embedded outlet pressuregauge with psi scale. (145 psi = 1.0 MPa = 10 bar). SEE PRODUCT PRECAUTIONS ON PAGES 17, 19 AND 21.

How to Order

Pressure range for regulator - Option:Blank for standard 5 to 125 psiL = 5 to 35 psiS = 5 to 60 psiFilter rating - Option:(blank for standard of 5 Series FA; Size 2, 3, 4 or 5Description: Filter, Regulator, LubricatorDrain (requires 15 psi min.):A = Auto drain, float typeM = Manual/Pressure differential drain FA3
– FRL2PA Port Size NPT:1P=1/8;2P=1/4;3P=3/8;4P=1/2;5P=3/4;6P=1 Gauge - Option:Blank for standardB = Block off plate C = 1/8 NPT adapter plateD = 1/4 NPT adapter plateF = Small round gauge with 1/8 NPT adapter plate G = Large round gauge with 1/4 NPT adapter plateM = Square embedded MPa scale
‡ µ for sizes 2, 3 & 4 ; 40 µ for size 5)1 = 5 µ ; 2 = 25 µ ; 3 = 40 µ
‡ Manual drain also opens as inlet pressure is reduced to less than 5 psi. Polycarbonate bowls arestandard for all models.

External Dimensions - inch (mm)

Size FA2Sizes FA3, 4 & 5 B Dimension
Body Size Port Size A C D E F G H J K L P Manual Drain Auto Drain Float type
FA2 FA3FA4FA5 1/8, 1/41/4, 3/8 1/2, 3/43/4, 1 5.5(140) 7.1(181) 9.4(238)11.1(282) 1.6(40) 1.7(44) 1.9(48) 1.7(43) 1.6(40) 2.1(53) 2.8(70) 3.5(90) 1.3(34) 1.2(30) 1.5(38) 3.3(84) 1.2(30) 1.6(41) 2.0(50) 2.8(70) 2.0(50) 2.5(64) 3.3(84) 3.8(96) 0.9(24) 1.4(35) 1.6(40) 2.0(50) 0.22(5.5) 0.28(7.0) 0.35(9.0) 0.47(12) 0.33(8.5)0.43(11) 0.51(13) 0.63(16) 0.2(5) 0.3(7) 0.3(7)0.4(10) 2.0(50)2.7(67.5)2.8(70)4.5(115) 5.5(140)6.3(160) 8.4(214)12.2(309.5) 5.3(134) 6.6(169) 8.4(213)11.7(297) Specifications and prices subject to change without notice or incurring obligation Page 4
