ORDERING INFORMATION

AXS-100-XX-XX-XX-XX-XX-XX-XX-XX-XX

Software summary kit

SK1 =SmartKit including macrobending detection,

pass/fail and fault finder SK2 = IP testing

SK3 = Fiber inspection probe software ^c

Probe option

00= Without probe

FP4S = Inspection probe (400x)

FP4D = Inspection probe (200x/400x)

VFL

00 = Without visual fault locator VFL = With visual fault locator

Connector adapter

FOA-12 = Biconic

FOA-14 = D4, D4/PC

FOA-16 = SMA/906

FOA-22 = FC, FC (PC/SPC/UPC/APC), NEC-D3 FOA-28 = DIN 47256 (LSA): DIN 47256 (PC/APC)

FOA-32 = ST, ST (PC/SPC/UPC) FOA-40 = Diamond HMS-0, HFS-3 (3.5 mm)

FOA-54 = SC (PC/SPC/UPC/APC)

FOA-76 = FSMA HMS-10/AG, HFS-10/AG

FOA-78 = Radiall EC

FOA-84 = Diamond HMS-10, HFS-13

FOA-96B = E-2000/APC

FOA-98 =LC FOA-99 =MU

Power meter

00 =Without power meter

PM2X = With GeX power meter

Example: AXS-100-023B-EI-EUI-89-04B-EA-EUI-91-

PM2X-FOA-22-VFL-FP4S-SK1-SK2-SK3

Model ■

AXS-100-003B= Access OTDR 1550 nm AXS-100-023B= Access OTDR 1310/1550 nm AXS-100-034B = Access OTDR 1550/1625 nm

AXS-100-000 = None ^a

Connector ■

EA-EUI-28 = APC/DIN 47256 EA-EUI-89 = APC/FC, narrow key EA-EUI-91 = APC/SC EA-EUI-95=APC/E-2000

EI-EUI-28 =UPC/DIN 47256

EI-EUI-76 = UPC/HMS-10/AG EI-EUI-89 = UPC/FC, narrow key EI-EUI-90 = UPC/ST EI-EUI-91 = UPC/SC

EI-EUI-95 =UPC/E-2000

Second port ■

00 = None

04B = Filtered 1625 nm ^b

Second connector ■

EA-EUI-28 = APC/DIN 47256 EA-EUI-89 = APC/FC, narrow key EA-EUI-91 = APC/SC EA-EUI-95=APC/E-2000

EI-EUI-28 =UPC/DIN 47256

EI-EUI-76 = UPC/HMS-10/AG EI-EUI-89 = UPC/FC, narrow key EI-EUI-90 = UPC/ST EI-EUI-91 = UPC/SC

EI-EUI-95 =UPC/E-2000

AXS-110-XX-XX-XX-XX-XX-XX-XX

Software summary kit

SK1 = SmartKit including macrobending detection, pass/fail and fault finder

SK2 = IP testing

SK3 = Fiber inspection probe software ^c

Probe option

00 = Without probe

FP4S = Inspection probe (400x)

FP4D = Inspection probe (200x/400x)

VFL

00 = Without visual fault locator VFL = With visual fault locator

Connector adapter

FOA-12 = Biconic FOA-14 = D4, D4/PC FOA-16 = SMA/906

FOA-22 = FC, FC (PC/SPC/UPC/APC), NEC-D3 FOA-28 = DIN 47256 (LSA): DIN 47256 (PC/APC)

FOA-32 = ST, ST (PC/SPC/UPC) FOA-40 = Diamond HMS-0, HFS-3 (3.5 mm)

Model ■

AXS-110-23B = Dual-wavelength SM OTDR 1310/1550 nm (9/125 nm)

AXS-110-12CD = Dual-wavelength MM OTDR 850/1300 nm

(50/125 nm, 62.5/125 nm) AXS-110-12CD-23B = Four-wavelength MM/SM all-fiber OTDR

850/1300 nm (50/125 nm, 62.5/125 nm) and 1310/1550 nm (9/125 nm)

Connector ^aB

EA-EUI-28 ^b = APC/DIN 47256 EA-EUI-89 ^b = APC/FC, narrow key EA-EUI-91 ^b = APC/SC EA-EUI-95^b = APC/E-2000 EI-EUI-28 = UPC/DIN 47256 EI-EUI-76 = UPC/HMS-10/AG EI-EUI-89 = UPC/FC, narrow key EI-EUI-90 = UPC/ST EI-EUI-91 = UPC/SC EI-EUI-95 = UPC/E-2000

Power meter ■

00 = Without power meter PM2X = With GeX power meter

FOA-54 FOA-76

SC (PC/SPC/UPC/APC) FSMAHMS-10/AG, HFS-10/AG

FOA-78 = Radiall EC

FOA-84 = Diamond HMS-10, HFS-13

FOA-96B = E-2000/APC FOA-98 =LC FOA-99 =MU

Notes

a Please refer to the example above. First select the singlemode connector, and then the multimode connector.

b. Singlemode only.

c. Mandatory with FP1 or FP5.

Example: AXS-110-12CD-23B-EA-EUI-89-EI-EUI-95-PM2X-FOA-22-VFL-FP4S-SK1-SK2-SK3
