Technical Data Subject to technical modifications; no responsibility is accepted for the accuracy of this information. 39 Safety switch STA with guard locking and guard lock monitoring Switch Parameter Value Unit Material Housing Anodized die-cast Mechanical life 1 x 106 operating cycles Ambient temperature - 20 ... + 55 °C Weight Approx. 0.6 kg Approach speed, max. 20 m/min Actuating force 35 N Extraction force (not locked) 30 N Retention force 20 N Locking force, max. 3000 N Locking force FZh in accordance with test principles GS-ET-19 2300 N Insertion depth (necessary minimum travel + permissible overtravel) Standard actuator S Actuator L for insertion funnel Approach direction side (h) 24.5 + 5 28.5 + 5 mm Approach direction from top (v) 24.5 + 5 28.5 + 5 mm Guard solenoid Solenoid operating voltage 24 +10%/-15% V DC (auxiliary power on black AS-Interface cable) Power supply unit with electrical isolation (IEC 60742, PELV) Solenoid operating current 300 mA Duty cycle 100 % AS-Interface connection Parameter Value Unit Connection Plug connector Version M12 (4-pin) Degree of protection according to IEC 60529 IP 67 2) Rated insulation voltage Ui 50 V AC/DC Switching principle SK, ÜK Slow-action switching contact 1 NC contact each EMC protection requirements Acc. to EN 50295 (AS-Interface standard) and IEC 62026 AS-Interface data Acc. to AS-Interface Specification 2.1 EA code: 7 ID code: B Total current consumption, max. 45 mA Valid AS-Interface addresses 1 - 31 AS-Interface inputs In accordance with AS-Interface Safety at Work Door monitoring contact SK D0, D1 Solenoid monitoring contact ÜK D2, D3 AS-Interface outputs D0 Guard locking solenoid, 1 = solenoid energized D1 Red LED, 1 = LED on D2 Green LED, 1 = LED on AS-Interface LED Power Green, AS-Interface voltage present AS-Interface LED Fault Red, offline phase or address 0 2) Screwed tight with the related plug connector Reliability figures according to EN ISO 13849-1 Parameter Value Unit B10d 1.2 x 107 operating cycles
