Safety Monitors Subject to technical modifications; no responsibility is accepted for the accuracy of this information. 29 AS-Interface Safety at Work safety monitor with integrated gateway GMOx
With integrated gateway to Profibus
One or two AS-i masters
Display and buttons for diagnostics and setup
Memory card for different operating modes
Adjustable time-delay
16 OSSDs Gateway to Profibus For connection to a Profibus DP as a slave and as a master for one or two AS-i buses according to specification 3.0. Recognition of ground shunt, double addressing and EMC problems. Rapid commissioning with the display without PC. Direct display of faults with plain-text messages. Comprehensive AS-i diagnostics integrated. AS-i configuration software is available. OSSDs, AS-i outputs
Two OSSDs (Output Signal Switching Devices) each with two redundant normally closed contacts
Two OSSDs (Output Signal Switching Device) with semiconductor outputs
12 additional safe AS-i outputs can be controlled. Inputs
4 inputs, freely selectable Logic functions Programmable with AsiMon software. All safety components can be programmed with different functions as inputs. The inputs can be linked with AND or ‚OR gates or via logic functions such as FlipFlop, switch-ondelay, turn-off delay or pulses. Programs can be stored for different operating modes on one memory card. AS-Interface monitor The monitor controls two AS-i circuits with up to 62 safe slaves and up to 16 outputs. Display and buttons The display is used to operate the gateway functionality as well as the monitor at the same time. The diagnostics and maintenance functions are considerably expanded compared to the SFM monitors. They can also be launched on the display without a PC monitor. Safety monitor GMOx Dimension drawing Block diagram <120> <100> <85> <90> <20> <6> Mounting on 35 mm DIN rail acc. to EN 50022-35 For connector assignment, see technical data on Page 57 Connection terminals AS-i removable Connection terminals safety monitor removable Memory card slot RS232 interface Profibus interface Please order connection set separately; see page 32 Incorporated security functions allow the programmed functionality to be protected and monitored. Power supply Type S is suitable for connection to a conventional AS-i power supply unit. Type N permits connection of several GMOx devices to the same power supply unit. Ordering table Series Bus connection AS-i master Number of AS-i outputs Power supply OSSDs Order no. / item 1 16 N 4 + 12 external 103267 GMOX-PR-12DN-C16 2 16 N 4 + 12 external 103302 GMOx PR GMOX-PR-22DN-C16 Profibus 1 16 S 4 + 12 external 103373 GMOX-PR-12DS-C16 2 16 S 4 + 12 external 103374 GMOX-PR-22DS-C16 Important: one connection set must be ordered for each safety monitor (see page 32). Profibus slave AS-i master 1 Inputs Safe outputs PWR AS-i 1 Y1.1 Y1.2 Y2.1 Y2.2 1.13 2.13 1.14 2.14 3.14 4.14 AS-i master 2 AS-i 2 AS-i master 2 only on GMOx...2...
