Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:6.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:14.00pt "Arial", sans-serif; } .font5 { font:18.00pt "Arial", sans-serif; } Non-Contact Safety Systems CMS EUCHNER Technical data read heads and actuators design A for ESM Value Parameter Unit min. typ. max. Read heads Housing material Reinforced PPS Ambient température - 20 +60 °C Degree of protection according to EN 60529 IP 67 Installation position Any, alignment with read head should be kept in mind (markings) Connection type Molded cable with crimped ferrules Switching current 24 V Switching current Ie 0.5 A Contact status indication (only CMS-R-AZA...) Switching current Switching current Ie 24 V 0.015 A Method of operation Magnetic, reed contact Mechanical life 100 x 106 operating cycles Vibration resistance 10 ... 55 Hz, amplitude 1 mm Shock resistance 30 g / 11 ms EMC compliance According to EN 60947-5-3 Center offset m from actuator ± 2.5 mm at a distance of s = 3 mm Switch-on distance Sao See ordering table and operating diagrams Switch-off distance Sar Contact elements Actuator Housing material Reinforced PPS Ambient temperature - 20 - +60 °C Degree of protection according to EN 60529 IP 67 Installation position Any, alignment with read head should be kept in mind (markings) Method of operation Magnetic Vibration resistance 10 ... 55 Hz, amplitude 1 mm Shock resistance 30 g / 11 ms Center offset m from read head ± 2.5 mm at a distance of s = 3 mm Switch-on distance Sao See ordering table and operating diagrams Switch-off distance Sar Operating diagrams design A for ESM typical switch-on distance typical switch-off distance Subject to technical modifications; no responsibility is accepted for the accuracy of this information. 51 /iir\
