Joystick Switches
Subject to technical modifications; no responsibility is accepted for the accuracy of this information. 19
Control versions
Centre position switch Z
(actuated in centre position)
Series KP... Analog Joystick
.. control panel installation at rear or with front plate
.. Analog, proportional output signals
.. Control variants with 1 and 2 axes or 2 axes simultaneously
.. Centre position switch
.. Pushbutton in handle
Dimension drawing
1 2 3
Pushbutton D
(with protective cap)
Interlock V
Bellows W
for panel mounting
86 / 4 x5,5
1) Panel cutout for assembly
with bellows W
1)
Bellows X
for surface
mounting
Versions 1 = 1 axis
Versions 2 = 2 axes
Versions 3 = 2 axes simultaneously (only spring return version)
