DATA
359
Technical data - ETITEC
Common power distribution systems (Europe)
Surge arresters group A
Circuit diagram
Technical data ETITEC A
Type 275/10; 275/15 440/10; 440/15
In accordance with IEC-61643-1
Category IEC / VDE II / C
Max. continuous operating voltage (AC/DC) Uc 280/350 V 440/580 V
Nominal discharge currnet (8/20) In 10 kA; 15 kA 10 kA; 15 kA
Max. discharge current (8/20) Imax 20 kA; 30 kA 20 kA; 30 kA
Protection level at In (8/20) 1,2 kV 2,2 kV
Response time tA <25 ns
Thermal decoupler yes
Torque max. 3,5 Nm
Temperature range -30OC ... + 80OC
Mounting outdoors
Casing material nylon P66 V-0
Surge arresters – ETITEC
Ř46
M8
90
67,2 13
